Section 4 Maintenance

Normal maintenance, service, and replacement of parts
are the responsibility of the owner/operator and, as such,
are not considered defects in materials or workmanship
within the terms of the warranty.
Poorly maintained equipment can become a safety hazard.
In order for the equipment to operate safely and properly
over a long period of time, periodic maintenance and
occasional repairs are necessary.
WARNING
Accidental Start-up. Disconnect the negative battery
cable, then the positive battery cable when working
on unit. Failure to do so could result in death
or serious injury.
Attach a "DO NOT START" sign to the control panel. This
will notify everyone that the unit is being serviced and will
reduce the chance of someone inadvertently trying to start
the unit.
For detailed engine maintenance procedures, refer to the
engine operator's manual, which was supplied with the unit
when it was shipped from the factory.
WARNING
Consult Manual. Read and understand manual
completely before using product. Failure to
completely understand manual and product
could result in death or serious injury.
Before servicing:
Verify that the key switch is turned to OFF and the
1.
negative (-) cable on the battery is disconnected.
If the pump or components are hot, allow adequate
2.
cooling prior to servicing the unit.
Close the suction and discharge valves.
3.
Vent the pump slowly and drain completely.
4.
Owner's Manual for Wet-Prime Trash Pumps
Risk of burns. Do not open coolant system
until engine has completely cooled.
Doing so could result in serious injury.
Do not allow compressed air to pressurize the pump or
vent-off compressed air through the pump, as this may
damage the pump and cause serious personal injury.
If this unit is used to handle any hazardous materials that
can cause injury or illness, take precautions by wearing
approved protective clothing and use appropriate safety
equipment.
(000130)
When servicing the unit, use only components provided by
the OEM or Generac Mobile Products, LLC. Any use of
non-authorized parts could result in sub-standard
performance, damage to equipment and possible injury to
personnel. Use of unauthorized parts will also void the
warranty.
Refer to Section 5
operational or performance problems. Only disassemble
the unit components required to remedy the problem
condition. Select a clean suitable location for any required
maintenance, and note that all work must be performed by
qualified personnel.

Daily Walk Around Inspection

Look for conditions that could hinder performance or safety,
(000100a)
such as (but not limited to) oil/coolant/fuel leakage, blocked
vents, loose/missing hardware and electrical connections.
Visually inspect the engine fan belt for cracks, fraying, and
stretching. Verify the belt is properly seated in pulley
grooves. Replace the belt according to the manufacturer's
recommendations.
Failure to perform a daily inspection may result in serious
damage to the prime mover.
Maintenance
WARNING
Troubleshooting to help diagnose
(000154)
