Analog Gauge Pages

Analog Gauge Pages provide four independent pages of
analog gauges. To enable Analog Gauge Pages, press any
of the first four buttons to show the top level button bar and
then press button 1 . Alternate pages are selected by
repeated pressing of button 1. The four standard gauge
pages are shown in Figure
NOTE: Engine Hours are displayed as a digital value
even on Analog Gauge Pages. The default gauge pages
represent 13 selections since the tachometer is repeated
in the upper right quadrant of each page.
All 16 gauges may be configured by the user to create an
application-specific view of CANbus data. Gauges on the
current page can be changed via Adjust mode, accessed by
pressing button 5 when the button bar is visible. Gauges
can be changed on any of the four pages by selecting the
page to be changed and then entering Adjust mode.
NOTE: Quad Adjust must be enabled to access the
Adjust mode.
Figure 3-6. Analog Gauge Pages
In Adjust mode, a new button bar is displayed identifying
the button functions. Button 1
upper left gauge, button 2
button 3 to the bottom left gauge and button 4
to the bottom right gauge. Successive presses of the
buttons selects a different parameter for the gauge. Adjust
mode is exited by pressing button 5
new configuration even when power is removed.
NOTE: A gauge selection can only appear once per
page. To move a gauge selection, the existing gauge
location must be changed first. Gauge selections are
limited to the data currently being received. Analog
Gauge Pages can be configured in Demo mode to select
Owner's Manual for Wet-Prime Trash Pumps
3-6.
corresponds to the
to the upper right gauge,
and storing the
any supported parameter. Refer to for a complete list of
available parameters.
Adjust mode can be disabled in the Configuration menu
(Quad Adjust - Off) to prevent accidental changes.

Digital Gauge Pages

Digital Gauge Pages display the same data as the Analog
Gauge Pages but in digital only format. To enable Digital
Gauge Pages, press any of the first four buttons to show the
top level button bar and then press button 2
pages are selected by repeated pressing of button 2. The
four standard Digital Gauge Pages are shown in
Figure 3-7. Digital Gauge Pages
NOTE: The 16 gauges are the same for Analog and
Digital Gauge Pages. Adjustments in either Analog
Gauge Pages or Digital Gauge Pages affect the same
gauge in the other mode.

Single Analog Gauge

Single Analog Gauge uses the entire display for a single
large analog gauge. This mode is enabled by pressing any
of the first four buttons to show the top level button bar and
then pressing button 3. The gauge displayed is selectable
by repeatedly pressing button 3
Analog Gauge mode while the menu bar is visible. The
currently displayed gauge is stored when power is
removed. Refer to Preferred Screen
Figure 3-8. Single Analog Gauge
Operation
. Alternate
Figure 3-7.
while in the Single
Store.
19
