Lifting the Unit

Remove the suction and discharge piping from the pump
prior to moving. Verify the equipment being used to lift the
unit is in good condition and has sufficient capacity.
Always remain aware of the position of other people and
objects around you as you move the unit.
A central lift point (A) is located on the top of the unit. Attach
any slings, chains or hooks directly to the lift point.
A. Central Lift Point
B. Tie down rings
Owner's Manual for Wet-Prime Trash Pumps
The tie down rings (B) at the front and back corners of the
trailer are intended for tie down use only.
A
B
B
Figure 3-5. Lifting Points
WARNING
Personal injury. Excessive weight. Use only
appropriate lifting eyes and lifting equipment to
lift unit. Improper lifting techniques could result in
equipment damage, death or serious injury. (000224)
Operation
003212
39
