GENERAL INFORMATION

General Specification

The Seametrics LevelSCOUT is a microprocessor based digital intelligent sensor designed
to measure and record level, temperature, and time, utilizing state-of-the-art low power,
battery operated circuitry.
Level is measured with an extremely rugged and stable piezo-electric media-isolated
pressure element combined with an analog-to-digital converter. This provides extremely
accurate and stable pressure input into the microprocessor on the circuit board.
Temperature is measured with an epoxy bead thermistor. The data is stored in non-
volatile memory. A serial communication link (RS485) provides communication to the
host computer.
Length (cabled version)
Length (cableless version)
Diameter
Body Material
Wetted Materials
Communication
Direct Modbus Read Output
Internal Math
Operating Temp. Range
Storage Temp. Range
Logging
Memory
Logging Rate
Software
File Formats
Power
Internal Battery
Expected Battery Life
Temperature
Element Type
Accuracy
Resolution
Units
Seametrics • 253.872.0284
6.6" (16.7 cm)
5.1" (12.9 cm)
0.875" (2.22 cm)
316 stainless steel or titanium
316 stainless steel or titanium, acetal, fluoropolymer
RS485 Modbus® RTU
32-bit IEEE floating point
32-bit floating point
-20° C to 60° C
-40° C to 80° C
50,000 records
1x per second
Complimentary Aqua4Plus 2.0
.csv / .a4d
One replaceable ½ AA 3.6 lithium battery
4.5 years (depending on use)
Thermistor
± 0.1° C
(from -20° C to 60° C)
0.01° C
Celsius, Fahrenheit, Kelvin
