- Page 1 IP800-Series Insertion Paddlewheel Flow Sensor Instructions PROUDLY MADE IN THE 9001:2008...
-
Page 2: Table Of Contents
Rotor Replacement ..............................Page 11 Signal Troubleshooting .............................Page 11 Sensor Replacement ..............................Page 11 Parts List ..................................Page 12 Troubleshooting Problems ..................................Page 13 Probable Causes ................................Page 13 Things To Try..................................Page 13 Warranty Seametrics Limited Warranty ..........................Page 14 Seametrics • 253.872.0284 Page 2 seametrics.com... -
Page 3: General Information
Low- AO55 blind analog transmitter can be used to convert to a flow performance is good, although other Seametrics flow 4-20 mA output. Electronic modules can be wall- or meter- meters are recommended where extremely low flows are mounted. -
Page 4: Specifications
#22 AWG 3-con, 18’ (6m); 2,000’ (610m) maximum cable run Note: 50’ (15m) maximum for battery powered or micropowered versions. Regulatory Mark *Specifications subject to change • Please consult our website for current data (www.seametrics.com). Kynar is a registered trademark of Arkema, Inc., Viton is a registered trademark of DuPont Corporation. Seametrics • 253.872.0284 Page 4... -
Page 5: Installation
Removal straight pipe requirements for your application. under pressure may result in damage or serious injury. Seametrics • 253.872.0284 Page 5 seametrics.com... -
Page 6: Straight Pipe Recommendations
INSTALLATION IP800-SERIES INSTRUCTIONS Straight Pipe Recommendations (X = diameter) Reduced Pipe Two Elbows In Plane Two Elbows, Out Of Plane Expanded Pipe Spiral Flow Propeller Meter Swirling Flow Partially Open Butterfly Valve Seametrics • 253.872.0284 Page 6 seametrics.com... -
Page 7: Full Pipe Recommendations
Caution: These flow sensors are not recommended for installation downstream of a boiler feedwater pump where installation fault may expose the flow sensor to boiler pressure and temperature. Maximum recommended temperature is 130°F (Plastic), 200°F (Metal). Seametrics • 253.872.0284 Page 7 seametrics.com... -
Page 8: Connections
For sensors with on-board electronics, see the manual accompanying the electronic module. RED (+) Low Power: 6-36 Vdc Micropowered: 3.1 - 16 Vdc WHITE Signal BLACK (-) Power FT430 FT430 Pulse Pass-thru 7-45Vdc Supply BLACK WHITE Pulse Responsive Metering Pump Flow Sensor Seametrics • 253.872.0284 Page 8 seametrics.com... -
Page 9: Ft440
Device 9-30 Vdc Loop Power Supply BLACK WHITE Electronic Metering Pumps Flow Sensor FT450 FT450 Pulse Pass-thru Lithium C, 3Vdc Replaceable Battery BLACK WHITE Pulse Responsive Metering Pump Current Sinking Micropower Polarity-Sensitive Flow Sensor Seametrics • 253.872.0284 Page 9 seametrics.com... -
Page 10: Operation And Maintenance
(www.seametrics.com). Pressure vs. Temperature (PVC/Polypro) 10031295 K: 53.6 MF81T-P200 P.S.I. Find Your K-Factor Here If a saddle or weld-type fitting has been ordered, use the K-factor calculator at the bottom of the seametrics.com 60˚ 70˚ 80˚ 90˚ 100˚ 110˚ 120˚... -
Page 11: Rotor Replacement
Slowly turn the rotor. Voltage reading should swing between -12 Volts and 0 Volts as the rotor turns. If it does not, the solid-state magnetic sensor is not working properly. Checking for continuity is not a useful test of these sensors. Seametrics • 253.872.0284 Page 11 seametrics.com... -
Page 12: Parts List
OPERATION AND MAINTENANCE IP800-SERIES INSTRUCTIONS IP800-Series Parts List IP800 Series Parts White Housing Blue Housing 1a thru 7a 1b thru 7b Upper housing/ Contact service Contact service electronics representative representative for your specific for your specific model model Housing gasket/seal... -
Page 13: Troubleshooting
Wrong time units on flow If using FT430, FT440, or FT520, check left side of indicator display (sec, min, hr, day); change to desired unit Seametrics • 253.872.0284 Page 13 seametrics.com... -
Page 14: Seametrics Limited Warranty
CONSEQUENTIAL DAMAGE CAUSED BY THE USE OR MISUSE OF, OR INABILITY TO USE THE PRODUCTS, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SEAMETRICS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT SHALL RECOVERY OF ANY KIND AGAINST SEAMETRICS BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SEAMETRICS AND CAUSING THE ALLEGED DAMAGE. - Page 15 IP800-SERIES INSTRUCTIONS Seametrics • 253.872.0284 Page 15 seametrics.com...
- Page 16 Seametrics • 19026 72nd Avenue South • Kent, Washington 98032 • USA LT-65200040r2.2-201612/30 (P) 253.872.0284 • (F) 253.872.0285 • 1.800.975.8153 • seametrics.com 12/30/16...
