Kohler Command Pro CV173 Service Manual page 9

CV200, CV224 Engine Dimensions-Flywheel Side
K
J
I
H
A 156.63 mm (6.167 in.)
E Air Filter and Cover
I Oil Fill and Dipstick
14 690 12 Rev. --
A
G
B 160.24 mm (6.309 in.)
F 193.30 mm (7.610 in.)
J 155.35 mm (6.116 in.)
KohlerEngines.com
B
F
C Fuel Fill
G 159.40 mm (6.276 in.)
K Recoil Rear Pull
Specifi cations
C
E
D
D 234.45 mm (9.230 in.)
H 243.27 mm (9.578 in.)
9
