Kohler Command Pro CV173 Service Manual page 14

Specifi cations
TORQUE SEQUENCES
Oil Pan Fasteners
Valve Cover Fasteners
TORQUE SPECIFICATIONS
Air Cleaner Base to Carb Studs
Nut
Blower Housing/Engine Cover/Retractable Starter
Stud
Brake (if equipped)
Mounting Fastener
Breather Cover
Fastener
Carburetor
Stud
Connecting Rod
Cap Fastener (torque in increments)
Cylinder Head (torque sequence on page 13)
Fastener (torque in 2 increments)
Dipstick Tube
Fastener
Values are in Metric units. Values in parentheses are English equivalents.
3
Lubricate threads with engine oil prior to assembly.
6
14
3,6
KohlerEngines.com
CV173 CV200
3
5
2
3
1
CV173 CV200
8 N·m (71 in. lb.)
10 N·m (89 in. lb.)
9.5 N·m (84 in. lb.)
10 N·m (89 in. lb.)
5 N·m (44 in. lb.)
12.5 N·m (111 in. lb.)
fi rst to 13 N·m (115 in. lb.)
fi nally to 25.7 N·m (227 in. lb.)
8 N·m (71 in. lb.)
CV224
1
6
4
2
4
CV224
14 690 12 Rev. --
