Install Muffl er Assembly
G
B
A
C
A Nut
C Muffl er
Barrel Baffl e
E
(CV200, CV224)
Muffl er Gasket
G
(CV173)
1. On CV200 & CV224 engines, slide barrel baffl e onto
exhaust studs. Tighten screw to secure barrel baffl e
to cylinder. Torque screw to 8 N·m (71 in. lb.).
2. Install new muffl er gasket onto exhaust studs.
3. Slide muffl er onto exhaust studs.
4. Install muffl er guard onto exhaust studs and secure
with nuts. Torque to 9.5 N·m (84 in. lb.).
14 690 12 Rev. --
F
D
E
B Muffl er Guard
Muffl er Gasket
D
(CV200, CV224)
F Exhaust Stud
KohlerEngines.com
Install Oil Drain Plug, Oil Filter, and Oil
A
D
C
A Oil Fill Cap/Dipstick
Clean Oil Change
C
Screw
1. Apply thread sealant around three full threads of
drain plug; reinstall drain plug. Torque to 13.6 N·m
(120 in. lb.).
2. Reinstall clean oil change screw. Torque to 14.7 N·m
(130 in. lb.).
3. Apply a thin fi lm of clean oil to rubber gasket on new
fi lter.
4. Refer to instructions on oil fi lter for proper
installation.
5. Fill crankcase with new oil. Level should be at top of
indicator on dipstick. Refer to Maintenance and
Lubrication System for oil recommendations and
procedures.
6. Reinstall oil fi ll cap/dipstick and tighten securely.
Install Fuel Cap
Screw fuel cap tightly onto fuel tank.
Reassembly
B
C
B
D
B Oil Filter
D Drain Plug
