Kohler Command Pro CV173 Service Manual page 41

Remove Muffl er Assembly
G
B
A
C
A Nut
C Muffl er
Barrel Baffl e
E
(CV200, CV224)
Muffl er Gasket
G
(CV173)
1. Remove nuts from exhaust studs and remove
muffl er guard.
2. Slide muffl er off studs.
3. Remove muffl er gasket from exhaust studs.
4. On CV200 & CV224 engines, loosen screw securing
barrel baffl e to cylinder and slide barrel baffl e off
studs.
Remove Retractable Starter
A
B
C
A Nut
C Stud
Remove nuts securing retractable starter assembly to
engine cover; lift starter off studs.
14 690 12 Rev. --
F
D
E
B Muffl er Guard
Muffl er Gasket
D
(CV200, CV224)
F Exhaust Stud
C
D
C
B Retractable Starter
D Engine Cover
KohlerEngines.com
Disassembly/Inspection and Service
Remove Engine Cover and Blower Housing
B
C
A Engine Cover
C Stud
1. Lift engine cover off studs.
2. Remove blower housing with inserts.
Remove Fuel Tank (if equipped)
B
A
A Screw
1. Ensure fuel tank is empty.
2. Detach fuel tank from crankcase by removing screw.
3. Remove studs securing top of fuel tank and lift off
tank.
A
C
C
B Blower Housing
B
B Stud
41
