Kohler Command Pro CV173 Service Manual page 51

NOTE: Make sure engine is assembled using all
specifi ed torque values, tightening sequences,
and clearances. Failure to observe specifi cations
could cause severe engine wear or damage.
NOTE: Always use new gaskets.
NOTE: Make sure all components have been properly
cleaned BEFORE reassembly.
NOTE: Remove all traces of cleaners before engine is
reassembled and placed into operation. Even
small amounts of these cleaners can quickly
break down lubricating properties of engine oil.
Install Crankcase Oil Seal
A Oil Seal
1. Make sure seal bore of crankcase is clean and free
of any nicks or burrs.
2. Apply a light coat of clean engine oil to outside
diameter of oil seal.
3. Drive oil seal into crankcase using a seal driver.
Make sure oil seal is installed straight and true in
bore to depth shown.
Install Governor Cross Shaft Oil Seal
A Oil Seal
1. Make sure seal bore of crankcase is clean and free
of any nicks or burrs.
2. Apply a light coat of clean engine oil to outside
diameter of oil seal.
3. Drive oil seal into crankcase using a seal driver.
Make sure oil seal is installed straight and true in
bore to depth shown.
14 690 12 Rev. --
A
B
B 0.5 mm (0.0197 in.)
B
A
B 0.5 mm (0.0197 in.)
KohlerEngines.com
Install Governor Cross Shaft
A
B
Governor Cross
A
Shaft
C Oil Seal
1. Lubricate governor cross shaft with engine oil.
2. Slide fl at washer on governor cross shaft and install
cross shaft from inside of crankcase.
3. Secure cross shaft with clip.
Reassembly
C
D
B Flat Washer
D Governor Shaft Clip
51
