Kohler Command Pro CV173 Service Manual page 17

CLEARANCE SPECIFICATIONS
Governor
Governor Cross Shaft-to-Crankcase Running
Clearance
Cross Shaft O.D.
New
Gear Shaft O.D.
New
Governor Gear Shaft-to-Governor Gear Running
Clearance
Ignition
Spark Plug Gap
Module Air Gap
Piston, Piston Rings, and Piston Pin
Pin Bore I.D.
Pin O.D.
Top and Center Compression Ring Side Clearance
Top and Center Compression Ring End Gap
Top
Center
Thrust Face O.D.
Piston Thrust Face-to-Cylinder Bore Running
Clearance
Valves and Valve Lifters
Intake and Exhaust Valve Lash
Intake Valve Stem-to-Valve Guide Running Clearance
Exhaust Valve Stem-to-Valve Guide Running
Clearance
Intake Valve Guide I.D.
Intake Valve Stem Diameter
Exhaust Valve Guide I.D.
Exhaust Valve Stem Diameter
Nominal Valve Face Angle
3 Values are in Metric units. Values in parentheses are English equivalents.
14 690 12 Rev. --
3
13.002/13.008 mm
(0.5118/0.5121 in.)
12.990/12.996 mm
(0.5114/0.5116 in.)
64.975/64.985 mm
(2.5580/2.5584 in.)
(0.0010/0.0014 in.)
KohlerEngines.com
CV173
0.020/0.064 mm (0.0007/0.0025 in.)
5.96/5.98 mm (0.2346/0.2354 in.)
6.01/6.03 mm (0.2366/0.2374 in.)
0.09/0.19 mm (0.0035/0.0074 in.)
0.76 mm (0.030 in.)
0.254 mm (0.010 in.)
0.001/0.020 mm 0.02/0.06 mm (0.0008/0.0024 in.)
(0.00004/0.00080 in.)
0.1/0.25 mm 0.15/0.30 mm (0.0059/0.0118 in.)
(0.0039/0.0098 in.)
0.61/0.76 mm 0.20/0.35 mm (0.0079/0.0138 in.)
(0.0240/0.0299 in.)
0.025/0.035 mm
0.0762/0.1270 mm (0.003/0.005 in.)
0.020/0.047 mm (0.0007/0.0018 in.)
0.055/0.082 mm (0.0021/0.0032 in.)
5.500/5.512 mm (0.2165/0.2170 in.)
5.465/5.480 mm (0.2151/0.2157 in.)
5.500/5.512 mm (0.2165/0.2170 in.)
5.430/5.445 mm (0.2137/0.2143 in.)
25°, 45°, 60°
Specifi cations
CV200 CV224
18.000/18.008 mm
(0.7086/0.7089 in.)
17.990/17.996 mm
(0.7082/0.7085 in.)
72.98/73.00 mm
(2.8732/2.8740 in.)
0.020/0.056 mm
(0.0008/0.0022 in.)
17
