Kohler Command Pro CV173 Service Manual page 43

Remove Breather Assembly
G
D
F
A Screw
Breather Cover
C
Gasket
E Disc (Breather Reed)
Upper Breather
G
Media
Breather system is designed to control amount of oil
in head area and still maintain necessary vacuum in
crankcase.
When piston moves downward, crankcase gases are
pushed past reed through mesh fi lter into intake system.
Upward travel of piston closes reed and creates a low
vacuum in lower crankcase. Any oil separated out
through fi lter drains back into crankcase.
1. Remove screws securing breather cover. Remove
cover.
2. Remove cover gasket; discard.
3. Remove breather cover spring, disc (breather reed),
then upper and lower breather media.
Remove Spark Plug
A
Remove spark plug from cylinder head.
14 690 12 Rev. --
A
B
C
E
B Breather Cover
Breather Cover
D
Spring
Lower Breather
F
Media
A
Spark Plug
KohlerEngines.com
Disassembly/Inspection and Service
Remove Flywheel Brake Assembly (if equipped)
A Screw
Remove screws and fl ywheel brake assembly from
crankcase.
Remove Valve Cover
A Valve Cover
C Valve Cover Seal
1. Remove screws from valve cover.
2. Remove cover and seal.
A
B
Flywheel Brake
B
Assembly
A
C
B
B Screw
43
