SC&T HE02P Quick Start Manual page 2

Cable:
Link cable recommend use high quality Cat.5e 、 Cat.6 、 Cat.6a 、 Cat.7 UTP / STP or FTP cable.
Poor quality cable or network connection or improper construction will cause unstable
connection, video or sound disruptions, picture noise appears.
Transmission Distance:
The maximum transmission distance up to 100meters, use lower resolution won't extend
longer distance
HDBaseT Distance chart by different cable:
Cable Type
CAT5e / CAT6
CAT6a / CAT7
If connection through the wall socket, the cable length must less 5 meters between HDMI
extender and wall jack, as below drawing:
Transmitter
< 5M
10/100Mbps network connection using general CAT5e cable and working distance up to 100M.
RJ45 Define:
LED Indication:
HDMI Port Status LED :
Color
Green Power
Blue IR Receive
Red IR Emitter
Range Pixel Clock Rate
100m <=225Mhz
70m
>225Mhz
100m
Wall Jack
LED Function
Video Data Rate
<=5.3Gbps
(HD Video)
>5.3Gbps
(Ultra HD Video)
MAX 100M
HE02PT
On: Power On
On: IR Received Signal
On: IR Emitting
Supported Video
Up to
1080p 60Hz 36 bpp
1080p 60Hz 48bpp,
1080p 60Hz 3D,
4K x 2K 30Hz
Wall Jack
< 5M
HE02PR
Receiver
2
