Lamp Socket Assembly

3
13
11
4
Reference
Number
1 7060A3055
2 7060A3007
3 7060A4007
4 7060A4008-02
5 7060A4011
6 7060A3011
7 7060A3012
8 HW748
9 7060B7019
10 HW534
11 7060A3025
12 HW746
13 HW5123
14 HW747
15 7060A3056
16 HW3103
17 HW5122
18 HW8209
19 7060B7003
20 W6195
21 HW749
22 7060B7007
23 7060A4037
24 HW2181
25 7060A3085
Lamp Socket Assembly
1
5
14
8
19
22
12
21
16
15
Part
Number
Housing, socket, casting, painted
Socket, light baffle casting, raw
Knob, X-Y, lamp set
Knob, Z, lamp set w/female insert
Bushing, cup
Hub, index, casting
Spring, lamp retainer
Spring, compression
Complete UL socket assembly
Nut, hex, 1/4-20, black zinc
Screw, 1/4-20 knurled head
Retaining ring, flat, Southco
Nut, hex, 9/16-18, black zinc
Washer, wave
Clamp, strain relief, painted
Screw, 8-32 x 5/8 PhFHMS, black zinc
Bolt, 1/4-20 x 1.75, full thread, black zinc
Clip Tinnerman
48" W420 wire, 16 gauge, 200° C/300V, green UL
1180/CSA AWM with lug J490T installed
36" sleeve, fiberglass
Spring, ground
4" W420 wire, 16 gauge, 200° C/300V, green, UL
1180/CSA AWM with two J490T lugs installed
Handle, insulated rear, black
Screw, 6-32 x 3/4, Taptite
Source Four Lamp Retainer Wire
20
22
6
7
9
Description
17
25
2
18
10
24
23
Figure 3
Quantity
Required
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
4
1
5
