Lamp Socket Assembly - ETC Source Four jr Assembly Manual

Lamp Socket Assembly

13
11
Reference
Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Lamp Socket Assembly
6
1
3
14
8
12
22
21
15
4
Part
Number
7060A3055
7060A3055-1
7060A3007
7060A4007
7060A4008-02
7060A4011
7060A3011
7060A3012
HW748
7060B7019
HW534
7060A3025
HW746
HW5123
HW747
7060A3056
HW3103
HW5122
HW8209
7060B7003
W6195
HW749
7060B7007
7060A3085
HW2125
20
5
19
7
16
Description
Housing, socket, casting, black
Housing, socket, casting, white
Socket, light baffle casting, raw
Knob, X-Y, lamp set
Knob, Z, lamp set w/female insert
Bushing, cup
Hub, index, casting
Spring, lamp retainer
Spring, compression
Complete UL socket assembly
Nut, hex, 1/4-20, black zinc
Screw, 1/4-20 knurled head
Retaining ring, flat, Southco
Nut, hex, 9/16-18, black zinc
Washer, wave
Clamp, strain relief, painted
Screw, 8-32 x 5/8 PhFHMS, black zinc
Bolt, 1/4-20 x 1.75, full thread, black zinc
Clip Tinnerman
48" W420 wire, 16 gauge, 200° C/300V, green UL 1180/CSA AWM
with lug J490T installed
36" sleeve, fiberglass
Spring, ground
4" W420 wire, 16 gauge, 200° C/300V, green, UL 1180/CSA AWM
with two J490T lugs installed
Source Four Lamp Retainer Wire
Screw, 6-32 x 3/8, PhFHTC, Type 1, zinc
22
17
23
2
18
24
10
9
Figure 2
Quantity
Required
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
3
