Assembly Guide
Production Dates: September 2004 - Present
ATTENTION:
The part numbers listed in this guide may differ from the parts
required for your particular Source Four fixture. Part numbers for
fixtures change occasionally as parts are replaced or upgraded.
To ensure that you are ordering the proper part for your specific
fixture, please contact your ETC dealer, or ETC Customer Service
for assistance.
Zoom
C o p y r i g h t © 2 0 0 7 E le c tr o n i c T h e a t r e C o n t r o l s , I n c .
P r o d u c t in f o r m a t i on a n d s p e c i f i c a t i o n s s u bj e c t t o c h a n g e .
A l l R i g h t s r e s e r v e d .
P a r t N u m b e r : 7060M2550-06.01 R e v A
R e l e a s e d : A u g u s t 2 0 0 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the source four zoom and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ETC source four zoom

  • Page 1 To ensure that you are ordering the proper part for your specific fixture, please contact your ETC dealer, or ETC Customer Service for assistance. C o p y r i g h t © 2 0 0 7 E le c tr o n i c T h e a t r e C o n t r o l s , I n c .
  • Page 2: Table Of Contents

    T a b l e o f C o n t e n t s 15°-30° Basic Fixture ........1 25°-50°...
  • Page 3: 30° Basic Fixture

    15°-30° Basic Fixture Figure 1 Reference Part Description Quantity Number Number Required 7060A2030 15°-30° lens tube 7060A2020 Reflector housing assembly, double clutch 7060A2008 Lamp socket assembly 7060A4008-01 Knob set with male insert 7060A4037 Handle, insulated rear HW5197 Screw, 1/4-20 x 5/8, black zinc HW2181 Screw, 6-32 x 3/4, black Taptite page 9...
  • Page 4: 50° Basic Fixture

    Step 7: Release the gel retaining clip by pushing it sideways while gently pulling backwards. Step 8: Insert the color frame. Step 9: Lock the clip by pushing sideways while gently pushing it forward. Source Four Zoom Assembly Guide...
  • Page 5: Lamp Socket Assembly

    Lamp Socket Assembly Figure 3 Reference Part Description Quantity Number Number Required 7060A3055 Housing, socket, casting, painted 7060A3007 Socket, light baffle casting, raw 7060A4007 Knob, X-Y, lamp set 7060A4008-02 Knob, Z, lamp set w/female insert 7060A4011 Bushing, cup 7060A3011 Hub, index, casting 7060A3012 Spring, lamp retainer HW748...
  • Page 6: Assemble Lamp Socket

    Secure with nut (10) and tighten securely (60 inch pounds). Step 14: Place the socket assembly (9) into the light baffle socket casting (2). Be sure it is well seated. Source Four Zoom Assembly Guide...
  • Page 7 Step 15: Install the lamp retainer spring (7). The lamp retainer spring secures the socket. Insert the spring one end at a time, making sure the rectangular slot in each side of the spring seats on the corresponding tab in the casting. N o t e : If the spring does not seat correctly, coax it into place with a screwdriver or needle- nose pliers.
  • Page 8 (15), then install the X-Y lampset (3) and Z lamp knob (4). Hand tighten the knob all the way to the right. C A U T I O N : You must install Z knob as described above to ensure proper lamp focus travel. Source Four Zoom Assembly Guide...
  • Page 9: Reflector Housing Assembly

    Reflector Housing Assembly (4 required) (2 required) (4 required) (4 required) Figure 9 Reference Part Description Quantity Number Number Required 7060A3054 Housing, reflector casting, painted black 7060A3006 Clip, reflector retainer 7060A4010 Bushing, gate 7060A3016 Plate, clutch 7060A3019 Spring, reflector support 7060A4015 Reflector, molded glass, coated 7060A3058...
  • Page 10: Installing Reflector

    Do not immerse or soak the glass in any cleaning solution. Remove dust with a blast of oil-free air or wipe with a clean, lint-free cloth. Isopropyl alcohol, distilled water or a 50%-50% mixture of each can be used to clean the glass surface. Source Four Zoom Assembly Guide...
  • Page 11: Front Barrel Assembly

    Front Barrel Assembly Figure 11 See detail to the right Shutter Assembly: The bottom divider plate (4) has four dimples punched into the surface; the top plate (6) has none. The middle divider plates (5) are noticeably thinner-gauge metal than the other two. Figure 10 Reference Part...
  • Page 12: Assemble Front Barrel Assembly

    (25 inch pounds). N o t e : The tops of the two front barrel castings must be even. Adjust as necessary before completely tightening the screws. Failure to do this could interfere with the barrel rotation. Source Four Zoom Assembly Guide...
  • Page 13 Step 10: Turn the front barrel assembly over so that the narrower end is on your work surface. Step 11: Install the four shutter springs (7) between the four dimples in the shutter plate and the tabs in the lip of the casting. N o t e : Install the springs at the joints in the castings on either of the tabs at the joint.
  • Page 14: 30° Lens Tube

    15°- 30° Lens Tube Front Barrel Assembly, page 9 15°-30° lens tube assembly Figure 12 15°-30° Gel frame endcap assembly Figure 13 Figure 15 Figure 14 15°-30° Rear lens assembly 15°-30° Front lens assembly Source Four Zoom Assembly Guide...
  • Page 15 1 5 ° - 3 0 ° L e n s t u b e a s s e m b l y Reference Part Description Quantity Number Number Required 7060A2030 15°-30° lens tube 7060A3139-01 Extrusion door See below Front lens assembly See below Rear lens assembly HW5218...
  • Page 16: 50° Lens Tube

    25°- 50° Lens Tube Front Barrel Assembly, page 9 25°-50° lens tube assembly Figure 16 Figure 17 25°-50° Gel frame endcap assembly 25°-50° Rear lens assembly 25°-50° Front lens assembly Figure 19 Figure 18 Source Four Zoom Assembly Guide...
  • Page 17 2 5 ° - 5 0 ° l e n s t u b e a s s e m b l y Reference Part Description Quantity Number Number Required 7060A2032 25°-50° lens tube 7060A3139-02 Extrusion door See below Front lens assembly See below Rear lens assembly HW5218...
  • Page 18: Assemble Lens Tube (15°-30° And 25°-50°)

    With the extrusion door open, place the gel cap (19) on the front of the unit and secure with four screws (20). Step 9: Once the gel cap is in place, close the extrusion door and turn the fastener (18) one-quarter turn clockwise to secure the baffle in place. Source Four Zoom Assembly Guide...
  • Page 19: Cleaning Glass Lens

    C l e a n i n g g l a s s l e n s W A R N I N G : Do not use ammonia-based or other harsh commercial cleaners. Clean lens only as directed. Commercially available glass cleaning agents should be avoided as they may contain ammonia, other harsh chemical detergents or abrasive agents.
  • Page 20 Hong Kong Rm 1801, 18/F, Tower 1 Phase 1, Enterprise Square, 9 Sheung Yuet Road, Kowloon Bay, Kowloon, Hong Kong Tel +852 2799 1220 Fax +852 2799 9325 Service: (Americas) service@etcconnect.com (UK) service@etceurope.com (DE) techserv-hoki@etcconnect.com (Asia) service@etcasia.com Web: www.etcconnect.com Copyright © 2007 ETC. All Rights Reserved. Product information and specifications subject to change. 7060M2550-06.01 Rev A Released 08/2007...
