EVAL-ADD8504/ADD8505/ADD8506
Table 4. Evaluation Board Components and Pin Descriptions
Label Description
A/B Switch pin (resistor string select)
C1 Power supply compensation capacitor (0.1 μF)
C2 Power supply compensation capacitor (0.1 μF)
C3 Power supply compensation capacitor (0.1 μF)
C4 Power supply compensation capacitor (0.1 μF)
C5 Power supply compensation capacitor (0.1 μF)
C6 Power supply compensation capacitor (0.1 μF)
C7 Power supply compensation capacitor (1 μF)
CLOAD1 Load capacitor for OUT1 (1 nF)
CLOAD2 Load capacitor for OUT2 (1 nF)
CLOAD3 Load capacitor for OUT3 (1 nF)
CLOAD4 Load capacitor for OUT4 (1 nF)
CLOAD5 Load capacitor for OUT5 (1 nF)
CLOAD6 Load capacitor for OUT6 (1 nF)
GND Ground
INA1 Input/probe pin for INA1
INB1 Input/probe pin for INB1
INA2 Input/probe pin for INA2
INB2 Input/probe pin for INB2
INA3 Input/probe pin for INA3
INB3 Input/probe pin for INB3
INA4 Input/probe pin for INA4
INB4 Input/probe pin for INB4
INA5 Input/probe pin for INA5
INB5 Input/probe pin for INB5
INA6 Input/probe pin for INA6
INB6 Input/probe pin for INB6
NC No connect
OUT1 Unloaded output probe pin for OUT1
OUT2 Unloaded output probe pin for OUT2
OUT3 Unloaded output probe pin for OUT3
OUT4 Unloaded output probe pin for OUT4

ORDERING GUIDE

Model
ADD8504-EVAL
ADD8505-EVAL
ADD8506-EVAL

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on
the human body and test equipment and can discharge without detection. Although this product features
proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy
electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance
degradation or loss of functionality.
©2006 Analog Devices, Inc. All rights reserved. Trademarks and
registered trademarks are the property of their respective owners.
Description
Evaluation Kit
Evaluation Kit
Evaluation Kit
EB05763-0-2/06(0)
Rev. 0 | Page 8 of 8
Label Description
OUT5 Unloaded output probe pin for OUT5
OUT6 Unloaded output probe pin for OUT6
OUT1_L Loaded output probe pin for OUT1
OUT2_L Loaded output probe pin for OUT2
OUT3_L Loaded output probe pin for OUT3
OUT4_L Loaded output probe pin for OUT4
OUT5_L Loaded output probe pin for OUT5
OUT6_L Loaded output probe pin for OUT6
RA1 First resistor in Gamma String A
RA2 Second resistor in Gamma String A
RA3 Third resistor in Gamma String A
RA4 Fourth resistor in Gamma String A
RA5 Fifth resistor in Gamma String A
RA6 Sixth resistor in Gamma String A
RA7 Seventh resistor in Gamma String A
RB1 First resistor in Gamma String B
RB2 Second resistor in Gamma String B
RB3 Third resistor in Gamma String B
RB4 Fourth resistor in Gamma String B
RB5 Fifth resistor in Gamma String B
RB6 Sixth resistor in Gamma String B
RB7 Seventh resistor in Gamma String B
RLOAD1 Load resistor for OUT1
RLOAD2 Load resistor for OUT2
RLOAD3 Load resistor for OUT3
RLOAD4 Load resistor for OUT4
RLOAD5 Load resistor for OUT5
RLOAD6 Load resistor for OUT6
R1 Pull-up/down resistor for A/B select (100 kΩ)
R2 Pull-down resistor for A/B select (1 MΩ)
SW1 MUX switch for GAMMA A and GAMMA B
VCC Power (+5 V)
