ORDERING INFORMATION

BILL OF MATERIALS

Table 3.
Qty Reference Designator
4 C1, C2, C7, C9
4 C3, C4, C8, C10
1 C5
3 C6, C11, C12
3 JP1, JP2, JP3
1 JP4
1 J1
1 J2
2 L1, L2
2 L3, L4
1 R1
2 R2, R3
1 U1

ORDERING GUIDE

Model
1
SSM2311-EVALZ
1
Z = RoHS Compliant Part.
Description
100 pF capacitor, 10%, 50 V
1 nF capacitor, 50 V
10 μF capacitor, 10 V
0.1 μF capacitor, 16 V
HDR1X2, connector header, 2-position
HDR1X3, connector header, 3-position
PWRJACK_PJ002A, connector
Audio jack, 3.5 mm, 3-pin
B0603, ferrite chip, 220 Ω, 2 A
15 μH
100 kΩ resistor, 1/10 W, 1%
0 Ω resistor, 1/10 W, 5%
SSM2311
Description
Evaluation Board
Rev. 0 | Page 9 of 12
Supplier/Part No.
Digi-Key 478-3717-1-ND
Digi-Key 399-3293-1-ND
Digi-Key 90-1843-1-ND
Digi-Key 399-1096-1-ND
Digi-Key A26508-02-ND
Digi-Key A26508-03-ND
Digi-Key CP1-021-ND
Digi-Key CP1-3523N-ND
Digi-Key 445-1565-2-ND
Not populated
Digi-Key 311-100KHRCT-ND
Digi-Key 311-0.0GRCT-ND
Analog Devices SSM2311

ESD CAUTION

EVAL-SSM2311
