Figure 14: battery cabinet internal view after removing the battery cover
(4) Insert the battery module into the battery module slot until it snaps into place. Please
refer to Figure 15.
NOTE:
1. Please pay attention to the cables on the left and right sides, which
do not hinder the loading of the battery modules.
2. When inserting the battery modules, please keep the cables from
sharp edges to avoid possible cut or damage of the cable insulation.
3. To consider the center of gravity, please install the battery modules
from the bottom layer of the battery module slot to the top layer of
the battery module slot in sequence.
