- Page 1 Alaris® Enteral Syringe Directions For Use Pump Model: 8002ENT01...
-
Page 2: Table Of Contents
Features of the Alaris Enteral Syringe Pump ........ -
Page 3: Introduction
All illustrations used in this manual show typical settings and values which may be used in setting up the functions of the Alaris Enteral Syringe Pump. These settings and values are for illustrative use only. Where stated, a minimum delivery rate refers to a nominal rate of 1.0ml/h, and an intermediate delivery rate refers to a nominal rate of 5.0ml/h. -
Page 4: Features Of The Alaris Enteral Syringe Pump
Alaris™ Enteral Syringe Pump Features of the Alaris Enteral Syringe Pump Features of the Alaris Enteral Syringe Pump ON/OFF High visibility Release lever Display Alarm Indicator for MDI PURGE MUTE PRESSURE OPTION Finger Grips Hook HOLD Shelf for chevron Syringe Clamp... -
Page 5: Controls And Indicators
Symbol Description ON/OFF button - Press once to switch the Alaris Enteral Syringe Pump on. Press and hold down for 3 seconds to switch the Alaris Enteral Syringe Pump off. RUN button - Press to start feeding. The green LED will flash during delivery. -
Page 6: Symbol Definitions
Date of Manufacture Manufacturer Not for Municipal Waste Fuse Rating +40°C Operating Temperature Range - Alaris Enteral Syringe Pump can be used between 0 and 40 degrees centigrade. 0°C EC REP Authorised Representative in the European Community 1000DF00601 Issue 7 5/34... -
Page 7: Main Display Features
Alaris™ Enteral Syringe Pump Main Display Features Main Display Features Pressure Syringe type fitted Status Information 0.00 Volume Volume Delivered VTBD Delivery Delivered Option Option Rate Screen Icons Symbol Description Time remaining display icon - Indicates time before syringe will require replacement. -
Page 8: Operating Precautions
Alaris Enteral Syringe Pump performance. • Secure the feeding tube to the Alaris Enteral Syringe Pump using the hook at the rear of the Alaris Enteral Syringe Pump. This provides protection against accidental dislodging of the syringe from the Alaris Enteral Syringe Pump. - Page 9 • This Alaris Enteral Syringe Pump is a CISPR 11 Group 1 Class A device and uses RF energy only for its internal function in the normal product offering. Therefore, its RF emissions are very low and are not likely to cause any interference with the nearby electronic equipment.
-
Page 10: Getting Started
• AC Power Cable (as requested) • Protective Packaging 3. Connect the Alaris Enteral Syringe Pump to the AC power supply for at least 2½ hours to ensure that the internal battery is charged (verify that the S is lit). - Page 11 The rotating cam can be fitted to the rectangular bar on the Docking Station/Workstation* or the equipment rail measuring 10 by 25mm. 1. Align the rotating cam on the rear of the Alaris Enteral Syringe Pump with the rectangular bar on the Docking Station/Workstation* or the equipment rail.
-
Page 12: Syringe Loading
• Use smallest syringe size possible, for example, if delivering 9 ml of fluid, use a 10 ml syringe. • Use the PURGE SYRINGE or PURGE option on the Alaris Enteral Syringe Pump to decrease the delay in the start of the delivery, see Starting the Alaris Enteral Syringe Pump section. - Page 13 Alaris Enteral Syringe Pump performance. Only use a syringe of the brand/model stated on the Alaris Enteral Syringe Pump display or in this manual. Using a non recognised enteral syringe type could adversely affect the accuracy of the delivery rate and may also affect Alaris Enteral Syringe Pump performance.
- Page 14 7. Ensure that the syringe type and size match those displayed on the Alaris Enteral Syringe Pump display then press CONFIRM. If required, the make of syringe can be changed by pressing the TYPE softkey.
-
Page 15: Starting The Alaris Enteral Syringe Pump
8. Connect the administration set to the patient access device. 9. Press to commence operation. • The amber stop light will be replaced by the flashing green start light to indicate that the Alaris Enteral Syringe Pump is in operation. RUNNING will be displayed. 10. Press to halt the operation. -
Page 16: Basic Features
Alaris™ Enteral Syringe Pump Basic Features Basic Features Bolus Delivery Bolus Administering a controlled volume of fluid or drug at an increased rate. Bolus can be used at the start of a delivery or during feeding. During BOLUS the pressure limit alarm is temporarily increased to the maximum level. - Page 17 1. Press the button when the Alaris Enteral Syringe Pump is not delivering. Ensure that the administration set is not connected to the patient. 2. Press and hold the PURGE softkey until fluid flows and the purging of the administration set is complete. The volume used during purging will be displayed, but it is not added to the volume delivered.
- Page 18 2. Select ADJUST ALARM VOLUME. Note: The Alaris Enteral Syringe Pump will beep at the selected alarm volume setting. The user must assess whether the alarm volume setting is loud enough for the intended operating environment, and adjust appropriately.
-
Page 19: Alarms And Warnings
If the Alaris Enteral Syringe Pump initiates a safety processor alarm condition (an audible high pitched continuous trill accompanied with a red alarm indicator) and there is no error message displayed on the Alaris Enteral Syringe Pump, remove the Alaris Enteral Syringe Pump from service for examination by a qualified service engineer. - Page 20 Indicator ATTENTION (with “3 Medium Amber Three beeps will sound if the Alaris Enteral Syringe Pump has been left on for Beeps”) more than 2 minutes (referred to as CALLBACK in the log) without starting the operation. Press the button to silence the alarm for a further 2 minutes. For...
-
Page 21: Configured Options
2. Select the option required to enable/disable or adjust and press the MODIFY softkey. 3. When all the required modifications have been carried out press the QUIT softkey. 4. Either select the next configuration option from the menu or turn the Alaris Enteral Syringe Pump off, returning it to operation as required. - Page 22 Sets the Near End Of Delivery warning time, as time left to End Of Delivery. 10 minutes EOD Point Sets the End Of Delivery point. The Alaris Enteral Syringe Pump will switch to running at the KTO rate when EOD is KTO Rate reached. 0.1ml/h VTBD Max Maximum permissible Volume To Be Delivered value.
-
Page 23: Specifications
0.1ml/h - 200ml/h 50ml syringes The Volume Delivered range is 0.0ml - 9990ml. The Alaris Enteral Syringe Pump displays Volume Delivered to 4 characters; however a volume delivered greater than 999ml will increment on the display in multiples of ten. Bolus Specifications... - Page 24 *95% lower confidence interval of 5 hours 50 minutes Charging takes 2½ hours from discharge to 90% charge. Memory Retention The electronic memory of the Alaris Enteral Syringe Pump will be retained for at least 6 months when not powered up. Fuse Type 2 x T1.25L250V AC Power Supply 115 - 230VAC, 50 - 60Hz, 37VA (under maximum charging conditions) 10VA (nominal).
- Page 25 Alaris™ Enteral Syringe Pump Specifications Electrical/Mechanical Safety Complies with EN/IEC60601-1 and EN/IEC60601-2-24. Complies with EN/IEC60601-1-2 and EN/IEC60601-2-24. Potential Equalisation Conductor The function of the Potential Equalisation Connector (Conductor) is to provide a direct connection between the pump and the potential equalisation busbar of the electrical installation.
-
Page 26: Recognised Syringe Types
Alaris™ Enteral Syringe Pump Recognised Syringe Types Recognised Syringe Types The Alaris Enteral Syringe Pump is designed to recognise single-use disposable enteral syringes. The table below lists the enteral syringes recognised by the Alaris Enteral Syringe Pump. Model 10ml 20ml... -
Page 27: Associated Products
Electrical Rating 460VA (Maximum) Protection Against Electrical Shock Class 1 Classification Continuous Operation Supply to pump 115-230V, ~50-60Hz, 60VA The Alaris DS Docking Station Product SKU 80283UNS00-xx Supply Voltage 230VAC, 50 or 60Hz Electrical Rating 500VA (nominal) Protection Against Electrical Shock... -
Page 28: Maintenance
AC power failure. Mean Time To Battery Empty from fully charged @ 5ml/h & 23°C under normal conditions is 6 hours*. From the battery low alarm it will take 2½ hours to 90% charge when reconnected to the AC power supply, whether the Alaris Enteral Syringe Pump is in use or not. - Page 29 If the Alaris Enteral Syringe Pump is to be stored for an extended period it should be first cleaned and the internal battery fully charged. Store in a clean, dry atmosphere at room temperature and, if available, employ the original packaging for protection.
-
Page 30: Irda, Rs232 And Nurse Call Specification
IrDA / RS232 / Nurse call Feature The IrDA or RS232 / Nurse call is a feature on the Alaris Enteral Syringe Pump that allows connection to a PC or another Alaris Enteral Syringe Pump. This allows data to be transferred between the Alaris Enteral Syringe Pump and a PC or another Alaris Enteral Syringe Pump, (e.g. - Page 31 Alaris™ Enteral Syringe Pump IrDA, RS232 and Nurse call Specification RS232 / Nurse call Connection Data Nurse call Specification - Connector D Type - 9 Pin TXD/RXD EIA RS232-C Standard TXD Output Voltage Range Minimum: -5V (mark), +5V (space) Typical: -7V (mark), +7V (space) with 3kΩ load to ground RXD Input Voltage Range -30V - +30V max.
-
Page 32: Occlusion Pressure Limits
Alaris™ Enteral Syringe Pump Occlusion Pressure Limits Occlusion Pressure Limits Time to alarm following occlusion is achieved in less than 30 minutes at rates of 1 ml/h and higher by the appropriate selection of occlusion levels. The following graphs show the typical values for time to alarm and bolus volume that can be expected in the event of an occlusion when the Penta Enteral 60 ml feeding syringe is selected with a Pentaferte standard administration set. -
Page 33: Trumpet Curves And Start-Up Curves
Alaris™ Enteral Syringe Pump Trumpet Curves and Start-up Curves Trumpet Curves and Start-up Curves In this pump, as with all infusion systems, the action of the pumping mechanism and variations in individual syringes cause short-term fluctuations in rate accuracy. The following curves show typical performance of the system in two ways: 1) the delay in onset of fluid flow when infusion commences (start-up curves), and 2) the accuracy of fluid delivery over various time periods is measured (trumpet curves). -
Page 34: Spare Parts
Spare Parts Spare Parts A comprehensive list of spare parts for this Alaris Enteral Syringe Pump is included within the Technical Service Manual. The Technical Service Manual (1000SM00001) is now available in electronic format on the World Wide Web at :- www.carefusion.co.uk/alaris-technical/... -
Page 35: Service Contacts
Alaris™ Enteral Syringe Pump Service Contacts Service Contacts For service contact your local Affiliate Office or Distributor. CareFusion, CareFusion, CareFusion, CareFusion, PO Box 5527, Tullastr. 8-12 Döbrentei tér 1, Avda. São Miguel, 296 Atelier 14 Dubai, United Arab Emirates. 69126 Heidelberg,... - Page 36 Alaris is a registered trademark of CareFusion Corporation or one of its subsidiaries. All rights reserved. All other trademarks are property of their respective owners. ©2018 CareFusion Corporation or one of its subsidiaries. All rights reserved. This document contains proprietary information of...
