Chassis Comparison

Chassis P/N PPC-6151C/6171C-RTAE
Purpose Highly optimized
Supported
mother board Must follow design guide
type
Daughter
Unnecessary
board
Riser card 2 slots
HDD kit 1
Speaker 2 x 1W
1. Decreasing number of cables
Advantage 2. Cost effective (w/o daughter
board)
Internal box
structure
I/O view
A. Power Switch
B. Reservation port
Note! Users can determine which chassis they are using by observing whether
the system features a USB port and a DP port. After identifying the
chassis type, refer to Chapters 2.3 and 2.4 (PPC-6151C/6171C-
RTAE&PPC-6151C/6171C-RMAE) for installation.
Note! When selecting a motherboard, please refer to the PPC-6151C/6171C's
selection guide.
PPC-6151C/6171C-RMAE
Highly compatible
Compatible with most Mini-ITX mother-
boards certified by Advantech
Necessary (additional cabling for external
USB and DP)
1 slot
2
Optional
1. Compatible with most Mini-ITX mother-
boards
A. Power Switch
C. AC inlet
B. Reservation port
D. PPC-MB-8260AE I/O port C. AC inlet
D. Mini-ITX M/B I/O port
3
E. USB2.0 (input, for connecting
M/B and touch controller)
F. Display port (input, for connecting
M/B and touch controller)
