Connect the Motherboard Wires
PPC-6151C/6171C-RTAE and PPC-MB-8260AE assembly
1. LVDS
6. Touch
7. DIO
8. COM3
9. COM4
10. COM5
11. Power switch
1. LVDS cable
6. Touch cable
12. Power conn.
Internal complete
connecting picture
Note!
1. The COM cable and DIO cable are the same.
2. The cable connection is based on the motherboard specifications.
2. Backlight
3. SYS FAN1
12. Power conn.
13. ATX_5VSB
2. Backlight
7. DIO
13. ATX_5VSB
4. SYS FAN2
5. HDD conn.
3.4. SYS FAN1,2
8.9.10.
COM3,4,5
14 . SPEAKER
17
PPC-6151C/6171C User Manual
15. LED conn.
14. SPEAKER
5. HDD cable
11. P ower switch
15. LED cable
