1.2 Setting up
1. Place the MCW-D 100 control unit in the same room as the transmitters.
2. Do not place the MCW-D 100 control unit near digitally controlled equipment.
3. Connect the receiving antennae to the antenna inputs A and B (5) using the appropriate adapter. For stand-alone-operation we
recommend using the CA 2411 angled rod antenna and the CA 2444 N(HF) Male - SMA Female adapter.
4. Connect the transmitting antenna to the antenna output (12). For stand-alone-operation we recommend using the CA 2411
angled rod antenna and the CA 2444 N(HF) Male - SMA Female adapter.
5. There must be an unobstructed path between the microphone units and the antennae. The range is around 50 m. For
optimum range the surface of the table is important, wood or plastic tables are ideal, but metal tables can cause interferences
and reduce the range.
6. Connect the XLR (10) or RCA (14) master output to the input of a mixing console/amplifier.
7. Connect the MCW-D 100 control unit to the mains (7). The internal power supply unit of the control unit can adjust automatically
between 110 V and 240 V.
8. Switch on the MCW-D 100 with the On/Off-switch (8) on the rear. The Power LED (1) on the front will illuminate green.
9. Depending on the configuration of the MCW-D 100 control unit 5 or more channel-LEDs will illuminate green (standard: 5 channels).
10. When mounting the MCW-D 100 control unit into a 19"-rack housing leave 1 HU for a ventilation panel.
Note
• If the system should fail to operate, i.e. the microphone unit is switched on but no sound is heard, press the reset button (3).
Should the system still fail to operate, please contact your beyerdynamic representative.
• If you press the standby button (2) for more than 3 seconds, you switch off all switched-on MCW-D microphone units within the range
of the MCW-D 100 control unit.
IMPOR IMPOR IMPORT T T T T ANT NO IMPOR IMPOR ANT NO ANT NOTE ANT NO ANT NO TE: To comply with FCC RF exposure compliance requirements, the following antenna installa- TE TE TE
tion and device-operating configuration must be satisfied. Only authorized and certified beyerdynamic systems
integrators may perform the installation of the antennas. There are no user serviceable parts or processes.
Connect the receiving antennae to the antenna inputs (5) A and B. Connect the transmitting antenna to the
antenna output (12). To maintain compliance with the FCC's RF exposure guidelines, this transmitter and its
antenna must maintain a separation distance of least 20 centimeters from all persons.
