APPENDIX A.
The following tables provide the pin assignments for the base unit, NIMs, and VIMs.
Base Unit Pinouts

Table A-1. CONSOLE Port Pinouts

Pin Name
1 DCD
2 RD
3 TD
4 DTR
5 SG
6 DSR
7 —
8 CTS
9 —

Table A-2. SFP Slot Pinouts

Pin Name
1 RX_LOS
2 RGND
3 RGND
4 MOD_DEF(0)
5 MOD_DEF(1)
6 MOD_DEF(2)
7 TX_DISABLE
8 TGND
9 TGND
10 TX_FAULT
61200796L1-34L
CONNECTOR PIN DEFINITIONS
Description
Data Carrier Detect (output)
Receive Data (output)
Transmit Data (input)
Data Terminal Ready (input)
Signal Ground
Data Set Ready Tied to pin 1 (output)
Unused
Clear to Send Tied to pin 1 (output)
Unused
Pin
11
12
13
14
15
16
17
18
19
20
Copyright © 2014 ADTRAN, Inc.
Name
RGND
RX_DAT-
RX_DAT+
RGND
VddR
VddT
TGND
TX_DAT+
TX_DAT-
TGND
