Option Modules

NetVanta E1/FE1 NIM (P/N 1200868E1)

The NetVanta E1/FE1 NIM (shown in
Series, meeting the requirements of ITU-T G.703/G.704. The module provides a single 2.048 Mbps
network interface. See Table A-6 on page 43
Operating Modes
• Frame Relay, multilink Frame Relay
• PPP, MLPPP
• HDLC
WAN-E1 Interface
• Supported Standards: ITU G.703,
ITU-T G.704 (CRC-4), ITU-T G.823,
ITU-T G.797
• Line Rate: 2.048 Mbps +50 PPM
• Line Code: AMI or HDB3
• Framing: FAS with optional CRC-4
• FE1 Line Rate: Channelized timeslot (in
multiples of 64 kbps)
• Receiver Sensitivity: -30 dB
• Connector: RJ-48C
Clock Source
• Network
• Internal
Diagnostics
• Test Pattern Generation and Detection:
QRSS, 511, all ones, all zeros
• Network loopbacks
• Network performance data (15 minutes
and 24 hours)
• Alarm generation and detection
26
NetVanta 7000 Series Hardware Installation Guide
Figure 5) provides an E1 WAN interface for the NetVanta 7000
for the pinouts. Dial backup (DBU) is not supported.
WAN-E1

Figure 5. NetVanta E1/FE1 NIM

Features and Specifications
Compliance
•
•
•
•
•
•
•
Environmental
•
•
•
Physical
•
Copyright © 2014 ADTRAN, Inc.
DBU
EMC - see Electromagnetic
Compatibility (EMC) Table on page
AS/ACIF S016
ETSI TBR 12/TBR 13
EN 60950
IEC 60950
AS/NZS 60950
RoHS compliant (1200868E1 only)
(Telecommunications exemption)
Operating Temperature: 0°C to 50°C
Storage Temperature: -20°C to 70°C
Relative Humidity: Up to 95 percent,
noncondensing
Dimensions: 2.75-inch W x 4.25-inch D
6.
