NetVanta 7000 Series Hardware Installation Guide

NetVanta Quad FXS VIM (P/N 1200690E1)

The NetVanta Quad FXS VIM (see
Table A-5 on page 42 for the FXS connector pinouts.
Analog Voice Ports
• Loop Start (LS), Ground Start (GS)
• Normal and reverse battery operation
Transmission Level
• FXS Receive Gain: -12 to +6 dB,
0.1 dB steps
• FXS Transmit Gain: -12 to +6 dB,
0.1 dB steps
Compliance
• EMC - see Electromagnetic Compatibility
(EMC) Table on page
• UL/CUL 60950
• RoHS compliant (1200690E1 only)
(Telecommunications exemption)
61200796L1-34L
Figure 10) adds voice capability to the NetVanta 7000 Series. See
1 2
ST TIONS

Figure 10. NetVanta Quad FXS VIM

Features and Specifications
6.
Copyright © 2014 ADTRAN, Inc.
3 4
N LOG
VIM
Environmental
• Operating Temperature: 0°C to 50°C
• Storage Temperature: -20°C to 70°C
• Relative Humidity: Up to 95 percent,
noncondensing
Physical
• Dimensions: 2.75-inch W x 4.25-inch D
Option Modules
31
