INSTALLATION
Select a Location
Install the communicator away from metal objects. Do not mount the communicator inside or on a control panel metal
enclosure. Mounting the communicator on or near metal surfaces impairs cellular performance.
Mount the Communicator
The communicator should be mounted to a wall using the included #6 screws in the mounting holes. See Figure 1.
Mount the communicator in a secure, dry place to protect the communicator from damage due to tampering or the
elements. It is not necessary to remove the PCB when installing the communicator.
A
Mounting Holes
B
Cellular Antenna
C
SMA Connector
Cell Modem
D
E
Tamper
B
C
B
C
Digital Monitoring Products
4
F
Programming Connection
Terminal Block
G
Load and Reset Buttons
H
Power and Armed LEDs
I
A
H
LOAD
RESET
D
+DC- Z1 Z2 Z3 G
+Z4- O1 O2
T R
E
G
CellCom-LTE-V
A
H
LOAD
RESET
D
+DC- Z1 Z2 Z3 G
+Z4-
O1 O2
T1 R1 T2
R2
E
G
CellComF-LTE-V
Figure 1: System Components
F
I
+DC- Z1 Z2 Z3 G
F
+DC- Z1 Z2 Z3 G
I
CellCom‑LTE Programming and Installation Guide
+Z4- O1 O2
T R
+Z4-
O1 O2
T1 R1 T2
R2
