TIME CHG NO YES
HRS FROM GMT: 6
KYPD INPUT
NONE ECP DSC

CID FORMAT

DMP CID
CellCom‑LTE Programming and Installation Guide

TIME CHANGES

Choose YES to allow the communicator to request automatic time changes from the
SCS‑1R or SCS‑VR receiver. The receiver must be programmed to send and receive time
change updates from the host computer at least every 24 hours. Choose NO to disable
automatic time change requests. The default is YES.

HOURS FROM GMT

When time zone is programmed YES, enter the number (0‑23) that indicates the
Greenwich Mean Time zone (GMT) where the communicator is located. The default is 6.
See Table 6 for GMT values.
GMT CITY/TIME ZONE
0 London, Monrovia, Lisbon
1 Cape Verde Island, Azores
2 Mid‑Atlantic
3 Buenos Aires, Georgetown
4 Atlantic Time (Canada), Caracas
5 Eastern Time (US, Canada) Bogota
6 Central Time (US, Canada) Saskatchewan 18
7 Mountain Time (US, Canada), Edmonton
8 Pacific Time (US, Canada), Tijuana
9 Alaska
10 Hawaii
11 Midway Island, Samoa

KEYPAD INPUT

Select NONE to allow zone 4 to function as normally programmed. The default is NONE.
Select ECP to enable communication between the communicator and an Ademco/
Honeywell panel using the +Z4‑ terminals. Using the Ademco/Honeywell ECP Bus, the
communicator can add, delete, and change user codes as well as arm and disarm the
Ademco/Honeywell panel. The communicator will forward alarm messages from the
Ademco/Honeywell panel to the central station.
Select DSC to enable communication between the communicator and a DSC PowerSeries
panel using the Z4‑ terminal. Using the DSC bus, the communicator can add, delete,
and change user codes as well as arm and disarm the DSC panel. The communicator will
forward alarm messages from the DSC panel to the central station.
See Ademco/Honeywell ECP Connection for examples of panel wiring and necessary
Ademco/Honeywell panel programming.
CID FORMAT
Select DMP to send CID messages as Serial 3 format. Select CID to send messages as DMP
string with raw CID message appended. Refer to Figure 16. Default is DMP.
This feature requires SCS‑VR Version 1.4.6 and higher or SCS‑150 Version 107 and higher.
The receiver sending
the message
The account number
of the DMP panel
9910 3155 c 5550 18 1 110 00 010 2
DMP String
GMT CITY/TIME ZONE
12
13
14
15
16
17
19
20
21
22
23
Table 6: GMT Time Zones
The message type
that identifies
the message as CID
The event code
for a Zone Fire Alarm
The account number
of the host panel
CID Identifier
The new event
CID String
Figure 16: CID Format Option
Fiji, Marshall Island, Wellington
New Cadelonia
Guam, Sydney
Tokyo, Seoul
Hong Kong, Singapore
Bangkok, Hanoi
Dhaka, Almaty
Islamabad, Karachi
Abu Dhabi, Kazan
Moscow, Bagdad
Eastern Europe
Rome, Paris, Berlin
Zone
Number
Partition
Checksum
Number
Digital Monitoring Products
