Dmx Chart - Event Lighting SABER2 User Manual

3-in-1 disco effect featuring derby, uv and strobe
Table of Contents

Advertisement

Menu
Display
Function
Addr
DMX Address
SLAV
Master/Slave
A1-1 ~ A1-9
Derby effects
A2-1 ~ A2-9
Derby effects
A3-1 ~ A3-9
Derby effects
A4-1 ~ A4-9
Derby effects
A5-1 ~ A5-9
Derby auto mode
A6-1 ~ A6-9
UV effects
A7-1 ~ A7-9
Strobe effects
A8-1 ~ A8-9
Combined Auto mode
S1-1 ~ S1-9
Sound mode 1
S2-1 ~ S2-9
Sound mode 2
S3-1 ~ S3-9
Sound mode 3

DMX Chart

CH
Function
1
Derby Motor rotation
2
Derby Motor rotation range
3
Derby Master dimmer
4
Derby Strobe
5
Derby effect
6
Derby effect
7
Derby effect
8
Derby effect
9
Derby Auto mode
10
Derby Speed Adjust
11
UV effect
12
UV strobe
13
Strobe effect
14
Strobe Speed
www.event-lighting.com.au
Value/Description
A001-A512
No/Yes
Red, 1-9 to adjust motor speed.
Green, 1-9 to adjust motor speed.
Blue, 1-9 to adjust motor speed.
White, 1-9 to adjust motor speed.
1-9 to adjust run speed.
No function. Manual UV control only allows one level.
1-9 to adjust strobe speed.
1-9 to adjust auto run speed.
Derby effect, 1-9 to adjust the sound sensitivity.
3-in-1 effect, Blackout when without sound,
1-9 to adjust the sound sensitivity.
3-in-1 effect, Light up when without sound,
1-9 to adjust the sound sensitivity.
Value
Description
000-127
Directional rotation
128-255
Rotate automatically, fast to slow
000-255
0 to 340 degrees
000-255
Dimmer 0-100%
000-010
No Strobe
011-255
Strobe, slow to fast
000-255
Red dimmer, 0-100%
000-255
Green dimmer, 0-100%
000-255
Blue dimmer, 0-100%
000-255
White dimmer, 0-100%
000-255
Derby Effect auto run
000-255
Auto run speed, slow to fast
000-255
UV dimmer, 0-100%
000-255
UV strobe, slow to fast
000-255
White dimmer, 0-100%
000-010
No strobe
011-255
Strobe, slow to fast
4
