2. ADJUSTING SHOE ANGLE
The angle of the shoe can be adjusted to allow for bevel cuts
between 0 and 45°.
1. Loosen the shoe locking
screws.
3. Tilt the shoe between
0-45° Left or Right.
5. Slide the shoe forwards.
7. Check the angle with a protractor by making a cut in a scrap
workpiece.
2. Slide the shoe
backwards.
6. Tighten the shoe locking
screws.

OPERATION

3. ON/OFF SWITCH

The tool is recommended for use with a residual current
device with a rated residual current of 30mA or less.
1. Connect the tool to the mains power supply.
2. Ensure your workpiece securely clamped.
2. To start cutting squeeze
the variable speed
switch.
Variable Speed Dial
4. For faster speed, rotate speed selection dial clockwise.
For slower speed, rotate dial anti-clockwise.
Lock On Switch
5. To lock the jigsaw on,
squeeze the variable
speed switch then the
lock on button.
7. To unlock the jigsaw,
squeeze and release
the variable speed
switch.
3. To stop cutting release
the switch.
6. Release the variable
speed switch, then the
lock on button.
