- Page 1 PRG-621V manual 23/3/04 5:40 PM Page 1 PLUNGE ROUTER 6.35mm OPERATING INSTRUCTIONS Always Wear Eye, Face & Ear Protection www.ozito.com.au...
- Page 2 PRG-621V manual 23/3/04 5:40 PM Page 2 SPECIFICATIONS - MODEL NO. MSH-115 SPECIFICATIONS - MODEL NO. PRG-621V Motor Size: 650W Input: 230V ~ 50Hz No Load Speed: 11500 – 32000 rpm Collet Size: 6.35mm (1/4”) & 8mm Features: Variable Speed...
-
Page 3: Electrical Safety
The electric motor has been designed for one voltage only. Always check that the power supply corresponds to the voltage on the rating plate. Note: 230V and 240V supply and Ozito tools are interchangeable for Australia and New Zealand. This tool is double insulated in accordance with EN 50144; therefore no earth wire is required. - Page 4 PRG-621V manual 23/3/04 5:40 PM Page 4 GENERAL 1. Keep work areas clean. Cluttered work areas and benches can cause accidents. 2. Consider work area environment. Keep the work area well lit. Do not use your tool where there is a risk of causing fire or explosion, e.g. in the presence of flammable liquids and gases.
- Page 5 Young children should be supervised to ensure that they do not play with this appliance. 22. Replacement of the supply cord. If the supply cord is damaged, it must be replaced by the manufacturer or an authorised Ozito Service Agent in order to avoid a hazard.
-
Page 6: Additional Safety Instructions For Routers
• If the supply cord is damaged, it must be replaced by the manufacturer or an authorised Ozito Service Centre in order to avoid a hazard. ASSEMBLY Before attempting any of the following operations, make sure that the tool is switched off and unplugged and that the spindle has stopped. - Page 7 PRG-621V manual 23/3/04 5:40 PM Page 7 ASSEMBLY (cont.) Fitting the Straight Guide Fence The straight guide fence helps to guide the tool parallel to the edge. • Insert the bars into the router base. • Set the guide fence to the required distance.
-
Page 8: Operation
PRG-621V manual 23/3/04 5:40 PM Page 8 OPERATION Plunge Lock Lever The plunge lock lever must first be pulled down in order to then change the position of plunge up or down. Once the plunge depth is set in the required position release the lever and it will automatically lock the plunge depth in place. - Page 9 PRG-621V manual 23/3/04 5:40 PM Page 9 OPERATION (cont.) Let the tool work at its own pace. Do not overload. • Carefully guide the power cord in order to avoid accidentally cutting it. Adjusting the Depth of Cut The depth of cut is the distance X between the depth rod and the 7 tier depth stop.
-
Page 10: Maintenance
You can use the tool without a guide. This is useful for signwriting and creative work. Only make shallow cuts. MAINTENANCE Your Ozito Router has been designed to operate over a long period of time with a minimum of maintenance. Continuous satisfactory operation depends upon proper tool care and regular cleaning. - Page 11 PRG-621V manual 23/3/04 5:40 PM Page 11 CONTENTS 1 x Router PRG-621V 1 x Spare Set of Brushes 2 x Collets (6.35mm and 8mm) 1 x Centring Pin 2 x Spanners 1 x Template Guide 1 x Straight Guide Fence 2 x Nuts &...
-
Page 12: Warranty
PURCHASED FROM: ________________________________________________ DATE PURCHASED: ________________________________________________ 3 YEAR REPLACEMENT WARRANTY Your Ozito tool is guaranteed for a period of 36 months from the ORIGINAL date of purchase under the following conditions: Professional, industrial or high frequency use will VOID this warranty.
