Pocket Cutting - Ozito JSW-4000U Original Instructions Manual

4. CUTTING
1. If using a vacuum
or extraction device,
first fit the dust
extraction adaptor
to the jigsaw.
2. Insert the correct
blade into the blade
holder with the teeth
facing forward.
3. Mark your cutting
line with a pencil.
4. Start the jigsaw. Allow
it to reach maximum
speed.
5. Place the base on to the workpiece and move forward with light
pressure.

5. POCKET CUTTING

A pocket cut is when you need to cut a hole in the middle of a
workpiece
1. Drill a hole in the
workpiece using a
12mm bit.
2. Pass the blade through the hole and begin the cut.
Tip: Use light pressure when making curved cuts.
JSW-4000U
