INSTALLATION
Figure 2
8
Find Quality Products Online at:
Below is a typical QS200 meter with labeled components. Familiarize
yourself with the meter before installation.
BLACK WIRE
GREEN LED
I.D. PLATE WITH
SERIAL NUMBER
AND FLOW ARROW
SIZE INFO
GlobalTestSupply
www.
RED WIRE
TYPICAL QS200 METER
INSERT ASSY.
AMBER LED
QUICK RELEASE
PIN
TEE
PAGE 8
