Flomec QS200 Product Owners Manual page 6

SPECIFICATIONS (CONTINUED)
Dimensions
A. Length
B. Height
C. Width
(at widest
point)
D. Depth
B
B
6
Find Quality Products Online at:
QS200-10,
QS200-10PW
1 INCH
4.25 in.
(108mm)
5.38 in.
(137mm)
2.50 in.
(64mm)
4.47 in.
(114mm)
C
SECT
For 1 in., 1-1/2 in., & 2 in. Meters
SECT
C
SECT
PAGE 6, FIGURE 1
PICTORIAL UPGRADE (PIN)
FOR 1", 1 1/2", 2" METERS
SECT
Figure 1
GlobalTestSupply
www.
QS200-15, QS200-20,
QS200-15PW QS200-20PW
1-1/2 INCH
2 INCH
4.90 in. 5.56 in.
(124mm) (141mm)
5.63 in. 6.12 in.
(143mm) (156mm)
2.50 in. 2.88 in.
(64mm) (73mm)
4.47 in. 4.94 in.
(114mm) (125mm)
A
A
For 3 in. & 4 in. Meters
QS200-30, QS200-40,
QS200-30PW QS200-40PW
3 INCH 4 INCH
6.63 in. 7.38 in.
(168mm) (187mm)
7.20 in. 8.41 in.
(183mm) (213mm)
4.18 in. 5.23 in.
(106mm) (133mm)
4.91 in. 6.17 in.
(124mm) (156mm)
D
SECT VIEW
(TEE ONLY)
D
SECT VIEW
(TEE ONLY)
