OPERATION

14 14 14
Find Quality Products Online at:
Each QS200 meter is shipped with two K-factor decals (placed loose inside
the owner's manual packet). One is to affix on or near the installed meter for
on-site use if desired. The other decal is to affix to a convenient spot on or
near the controller for immediate reference if desired.
LEDs Functionality
There are two LEDs on the QS200 product. The GREEN LED is used
to indicate basic power and functionality of the meter. The AMBER LED
is used to indicate that there is a flow of water through the QS200 meter
insert. The LEDs will behave in the following manner to indicate different
modes of operation:
MODE
Power Disconnected
or Meter Failure:
No Flow Low
Power Mode:
No Flow or Reverse
Flow Active Mode:
Low Flow
Active Mode:
**High Flow
Active Mode: AMBER LED will appear to be constantly ON, but
**NOTE: To save power it is normal for the LEDs to be dim when flashing at
higher flow rates. At very high flow rates, the AMBER LED will appear to be
constantly ON but dim.
GlobalTestSupply
www.
LED BEHAVIOR
Both GREEN and AMBER LEDs are OFF.
GREEN LED flashes ON/OFF at a rate
of approximately 2 blinks per second.
GREEN LED flashes ON/OFF at a rate
of approximately 8 blinks per second.
GREEN LED flashes ON/OFF at a rate of
approximately 8 blinks per second and the
AMBER LED flashes ON/OFF at a rate that is
proportional to the rate of water flow thru the
meter.
GREEN LED flashes ON/OFF at a rate of
approximately 8 blinks per second and the
will be dim.
