Lower Controls - Mec Speed Level 3084ES Operator's Manual

Secton 12 - Component Locatons
Raise
2
(Green)
Lower
3
(Green)
Battery
8
Disconnect
Keyswitch
1
Charge Indicator 6
ART_3245
CONTROL
1 Selector Switch
2 RAISE Button
3 LOWER Button
EMERGENCY STOP
4
Switch
5 Hour Meter
6 Charge Indicator
7 Circuit Breaker
8 Battery Disconnect
EMERGENCY
9
LOWERING Switch
Overload
10
Indicator Light
Page 39

Lower Controls

Emergency Stop
4
PLATFORM Select to operate from the platform control panel.
BASE Select to operate from the base control panel.
OFF Select to stop operation from either control panel.
Press and hold to elevate the platform. Release to stop elevation.
Press and hold to lower the platform. Release to stop lowering.
Press to stop all machine functions. Turn clockwise to reset.
Indicates total elapsed time of machine operation.
Indicates state of battery charge.
Trips when there is excessive electrical load. Push to reset.
Battery power supply. Turn OFF and padlock to secure machine from
unauthorized use.
Push and hold the toggle switch Down to fully lower the platform.
Light ON indicates too much weight on the platform.
An audible alarm will sound and all machine function will stop.
Remove weight from the platform to restore function and continue.
3084ES Speed Level TM
Hour Meter
5
DESCRIPTION
- Operator's Manual
August 2020
Overload
10
Indicator Light
Emergency
9
Lowering
Circuit
7
Breaker
