LFtNg And TE Down InstructOns - Mec Speed Level 3084ES Operator's Manual

Secton 16 - Transport and Lftng Instructons
• Fully lower the platform. Be sure the module doors are closed and secure. Remove all loose
items from the machine.
• Fold down the guardrails.
• Determine the center of gravity of the machine.
• Attach rigging to the designated lift points only.
• Adjust the rigging to prevent damage to the machine and to keep the machine level.
Securing to Truck or Trailer for Transport
• Turn the key switch to OFF and remove the key before transport.
• Turn the battery disconnect switch to OFF before transport.
• Inspect the entire machine for loose or unsecured items.
• Use chains or straps of ample load capacity.
• Use a minimum of two (2) chains or straps.
• Adjust the rigging to prevent damage to the chains and the machine.
Center of Gravity and Lifting Points
Center of Gravity
3084 45.89 in. / 116.57cm
Y Axis
X Axis
ART_3104
Page 48
Lifting and Tie Down Instructions
Only qualified riggers should rig and lift the machine�����
Ensure that the crane capacity, loading surfaces and straps are sufficient
to withstand the machine weight����� See the serial plate for the machine
weight�����
X Axis Y Axis
10.89 in. / 27.65 cm
3084ES Speed Level TM - Operator's Manual
August 2020
