Secton 8 - Fold Down Platform Ralngs
Page 22
4
ART_3140
5
ART_3141
6
ART_3142
7
ART_3143
3084ES Speed Level
Lower the Entry Rail
• Lower the entry guardrail to the platform
floor.
• Return the snap pins to their places.
Release Left Side Rail
• Remove the 3 snap pins from the base the
guardrail with the loading gate.
Lower Left Side Rail
• Lower the guardrail and loading gate to
the platform floor.
• Return the snap pins to their places.
Release and Lower Right Side Rail
• Remove the 3 snap pins from the base of
the right side guardrail.
• Lower the guardrail to the platform floor.
• Return the snap pins to their places.
Reverse the procedure to erect the guardrails.
