Mec Speed Level 3084ES Operator's Manual page 41

Secton 12 - Component Locatons
Modules
GP400
Module
Power Module
12 Volt DC Battery
Emergency Lowering
48 Volt DC Battery Pack
Eight 6 Volt DC Batteries
ART_3099
Page 37
Control Module
Alarm Battery
Disconnect Switch
Terminal Block
Module
Lower Controls
Emergency
Lowering Switch
48 Volt DC
Battery Charger
Main
Hydraulic
Manifold
Hydraulic Fluid
Sight Gauge
3084ES Speed Level
GP600
Motor Controller
15
BR AM
EA P
KE
R
Hydraulic Fluid
Pump and Motor
Battery Charger
AC Connector
TM - Operator's Manual
August 2020
Leveling
Manifold
Hydraulic Fluid
Filter
Hydraulic
Reservoir
Power to Platform
AC Connector
