Secton 6 - Functon Tests and Operatng Instructons
Joystick Operation
Steer
Proportional
Joystick
F o r w a
r d
R e v e r
s e
L o w e r
L if t
Enable
Bar
ART_2363
ART_3259
IMPORTANT: Always check front steer wheel direction before driving.
Page 17
Function speed is proportional and is controlled by the movement of the
joystick.
The further it is moved forward, the faster the speed will be.
The joystick returns to the neutral (center) position when released.
Do not elevate platform unless guardrails are installed and secure – see
"Fold Down Platform Railings" on page 21�����
If the platform fails to lower DO NOT attempt to climb down the elevating
assembly����� Serious injury may result – see "Emergency Systems" on page
20�����
Elevate Platform
• Place the MODE SELECT switch in the LIFT position.
• Squeeze the enable bar and move the joystick toward you.
Test Operation
• Rate of lift is proportional and is dependent on the movement of the
joystick.
• Elevate to maximum height.
• Releasing the enable bar or the joystick will stop elevation.
• Pressing the EMERGENCY STOP switch will stop elevation.
Lower Platform
• Place the MODE SELECT switch in the LIFT position.
• Move the joystick away from you.
Test Operation
• Rate of descent is fixed - platform lowers at same rate regardless of
handle position.
• Pressing the EMERGENCY STOP switch will stop descent.
Check that the route is clear of persons, obstructions, debris, holes and
drop -offs, and is capable if supporting the machine�����
