Section 8 - Fold Down Platform Railings; Fold Down Platform RaLNgs - Mec Speed Level 3084ES Operator's Manual

Secton 8 - Fold Down Platform Ralngs
Page 21
Fold Down Platform Railings Fold Down Platform Railings
ART_3137
ART_3138
ART_3139
3084ES Speed Level
Open the Loading Gate
1
• Remove the 2 snap pins that
hold the loading gate to the side
guardrail.
Secure the Loading Gate
Swing the loading gate open
2
• Secure the gate to the side
guardrail using 1 of the 2 snap
pins.
• Return the other snap pin to its
place.
Release the Entry Rail
• Remove the 2 snap pins from the
3
top corners of the entry guardrail.
• Remove the 2 snap pins from the
base of the entry guardrail.
