Overview; Four Output Wptv Reference Chart; Specifications; Installation Instructions - Altronix WPTV244UL Series Installation Manual

Altronix WPTV244UL Series outdoor CCTV Power Supplies provide power via four (4) protected outputs for
CCTV Cameras, heaters, and other video accessories.
Units are UL Listed UL2044 "U.S. and Canada for CCTV Equipment."
Altronix Output
Model Number Voltage
24VAC
WPTV244175UL
28VAC
24VAC
WPTV244300UL
28VAC
Agency Listings:
• UL Listed for Commercial CCTV Equipment
(UL2044).
• CUL Listed - CSA Standard C22.2 No.1-98,
Audio, Video and Similar Equipment.
• CE European Conformity
Input:
• 115VAC, 50/60Hz.
Output:
• Four (4) protected outputs:
- One (1) fuse protected non power-limited output.
- Three (3) Class 2 Rated PTC protected
power-limited outputs rated @ 2.5A.
Unit should be installed in accordance with The National Electrical Code and all applicable Local Regulations.
1. Remove back plate inside enclosure by removing the four (4) mounting screws (Figs. 2a, 3a, pgs. 4, 5).
2. Mark and drill desired knockouts on the enclosure to facilitate wiring (Fig. 1, pg. 3).
3. Secure back plate inside enclosure with the four (4) mounting screws (Figs. 2a, 3a, pgs. 4, 5).
4. Unit can be wall or pole mounted.
Wall Mount:
- Mark and drill holes to line up with the top and bottom holes of the enclosure flange.
- Secure enclosure with appropriate fasteners (Enclosure Dimensions, pg. 8).
Pole Mount:
- Refer to the detailed pole mount instructions (pg. 6).
Secure enclosure to earth ground.
5. Set power switch to OFF position (Figs. 2b, 3b, pgs. 4, 5).
6. All units are factory set for 24VAC operation.
For 28VAC operation adjust unit prior to mounting and applying power as follows: change the wire position
so that the black wire [28V] is connected to the terminal marked [P] and the yellow wire [24V] is connected
to the terminal marked [S].
Keep power-limited (PTC protected outputs only) wiring separate from non power-limited wiring.
Minimum 0.25" spacing must be provided. Use separate entries.
7. Measure output voltage before connecting devices. This helps avoiding potential damage.
Terminals marked [1P - 4P] are of the same polarity.
CAUTION: Determine the maximum operating voltage of the equipment being powered before
adjusting the output voltage.
8. Connect devices to terminals marked [1P - 1N] through [3P - 3N] on board (Figs. 2, 3, pgs. 4, 5), carefully
observing polarity. Connect high current device to output (4P - 4N).
9. Turn main switch to the ON (RESET) position (Figs. 2b, 3b, pgs. 4, 5).
10. Green LED will illuminate when unit is powered.
11. Upon completion of wiring secure enclosure door with the cam lock (supplied).
- 2 -
Four (4) Output WPTV Reference Chart:
Total
Output
Current
7A
4
6.25A
12.5A
4
10A

Specifications:

Installation Instructions:

Overview:

Output Current
(max per output)
PTC Protected
2.5A (1A per
3 1
output max)
2.5A (1A per
3 1
output max)
Features:
• AC power LED.
• Illuminated power disconnect circuit breaker
with manual reset.
• Surge suppression.
• Spare fuses provided.
• NEMA 4 Rated enclosure for outdoor use.
Enclosure Dimensions (H x W x D approx.):
12" x 8" x 6" (304.8mm x 203.2mm x 152.4mm).
Fuse
Protected 115VAC
Output 50/60Hz
Rating Input Current
10A/250VA 1.76A
15A/32VA 2.7A
WPTV244UL Series
