Altronix WPTV244UL Series Installation Manual page 4

Fig. 2
WPTV244175UL
F1
1P, 2P, 3P, 4P = FUSED OUTPUTS
1N, 2N, 3N, 4N = COMMON OUTPUTS
1P 1N
- 4 -
F2 F3
2P 2N 3P 3N
Power Distribution Board Terminals:
1P 1N 2P 2N
PTC protected outputs 1 through 3.
Power-limited, Class 2 Rated,
2.5A max per output.
Transformer Hookup:
F4
PD4A
LED
4P 4N
N P
Green
Ground
Wire
Input 115VAC, 50/60Hz
3P 3N 4P 4N
Non power-limited,
fuse protected output
(see Reference Chart)
White
INPUT
S
Terminal Blocks for Fig. 2
Input from
transformer.
24V Configuration
N P S
Illuminated Power Switch:
Fig. 2a
Fig. 2b
Illuminated
Power Disconnect
Circuit Breaker
with manual reset
Input from
transformer.
28V Configuration
N P S
WPTV244UL Series
