NO. DESCRIPTION
1L/R Upright frame
2 Cross beam
3 Stabilizer
4 Barbell holder
5L/R Olympic bar slider
6L/R Stopper hook
7 Allen bolt M10*25
8 Safety buckle
9 Rubber bumper
10 Fixing spacer
11 Bearing 6203
12 Bearing 60/28RS
13 Inner C-Clip Φ52
14 Plastic spacer
15 Olympic bar
16 Allen cylindrical bolt M10*35
17 Alloy bushing I
18 Inner C-Clip Φ30
19 Bearing 6200
20 Pulley
21 Nylon nut M10
22 Pulley bracket
23 Allen bolt M8*16
24 Allen flat head bolt M5*35
25 Hex nut M5
26 Leveller feet
27 Hex nut M10
28 Washer Φ40*Φ10*4
NOTE:
Most of the listed hardware has been packaged separately, but some of them have been
preinstalled in the identified assembly parts. In these instances, simply remove and
reinstall the hardware as assembly is required.

PARTS LIST

QTY NO. DESCRIPTION
1/1 29 Oval rubber feet
2 30 Guide rod bumper
1 31 Olympic bar guide rod
2 32 Stopper hook bushing
1/1 33 Guide rod spacer joint
1/1 34 Spacer Φ14*Φ10*38
18 35 Stabilizer step pad
2 36 Phillips flat screw M4*12
2 37 Inner C-Clip Φ48
2 38 Linear bearing
2 39 Plastic stopper
2 40 Allen cylindrical bolt M8*30
2 41 Safety pin
2 42 Track bar
1 43 Cable
12 44 Balance stack
8 45 Small roller
4 46 Phillips screw M5*25
4 47 Curved end cap
4 48 Barbell rack bolt Φ16*166
4 49 Barbell rack collar
4 50 Plastic barbell rack
8 51 Allen cylindrical bolt M10*16
4 52 Allen cylindrical bolt M10*20
8 53 Allen cylindrical bolt M8*50
2 54 Nylon nut M8
2 55 Safety hook
4 56 Alloy bushing II
- 4 -
QTY
4
4
2
4
2
2
2
6
4
4
2
2
40
2
4
2
8
8
4
6
6
6
2
4
2
2
2
16
