Excelon EZ Operator's Manual
50
• According to the Edging Options, Beveling position can be selected
independently.
☞
☞
☞
☞
Adjust the position according to the Lens Base Curve and the Minimum
Thickness (0~10)
• The value of the edging options affects the final output as followings :
• Like the above picture, if the operator use ratio(%) mode from the Front side
about a so thin lens, the machining of the thinnest part could be dangerous.
• Using the distance(mm) mode from the front side, the operator can designate
the specific distance, However, if the thickness of the thin area is less than the
Operation Tips
Ratio (%) from the Front side of the lens
Distance (mm) from the Front side of the lens
Distance (mm) from the Rear side of the lens
50%
1.6mm
30%
[ Ratio(%) mode
from the front side ]
50%
[ Distance(mm) mode
from the front side ]
1.6mm
