Bill of materials

Table 4.
Part
U1
U7
U71
U9
Table 5.
Part
C114, C115,
C116, C117
C707, C708
C30, C40, C50
C03
C02
C61
C07, C09,
C714-C715,
C85-C88
C05, C118,
C701-C705,
C706, C709,
C711-C713,
C90,
C101-C112,
C710
C06
C08
C01
C04
Table 6.
Part
X1
X2
X2B
Chips
Package
STR912FAW34, STR912FAW42,
LQFP128
STR912FAW44
TQFP64 Ethernet physical layer
SOT23-6L DALC208 diode protection
SO8 CAN transceiver (3V)
Capacitors
Package
0603 18 pF (16-22 pF), ceramic
0603 10 pF (8-16 pF), ceramic
0603 10 pF
0603 22 pF
0603 220 pF
0603 4.7 nF, ceramic
0603 10 nF
0603 100 nF
AB 2.2 µF
AB 10 µF
CDE 10 µF, 35V, Tantal or ceramic
CDE 100 µF, 10V, Tantal
Xtals
Package Detail description
- 25 MHz
- 32 kHz
Detail description
Detail description
KOALA: 25MHz CM5032
KOALA: 32.768 MC146
GM: 131-082 (Q32.768KHZM)
STR9 Dongle
Order code
ST: STR912FAW34x6,
STR912FAW42x6,
STR912FAW44x6
ST: STE100 or STE101
ST: DALC208SC6
Farnell: 501-1954
(SN65HVD230-232)
Order code
Farnell: 422-6768 (NPO, 50 V)
Farnell: 422-6768 (NPO, 50 V)
Farnell: 422-6770 (NPO, 50 V)
Farnell: 422-6811 (NPO, 50 V)
Farnell: 422-6926 (X7R, 50 V)
Farnell: 422-6938 (X7R, 50 V)
Farnell: 422-6859 (X7R, 16 V)
Farnell: 757-720 (STD, 10 V)
Farnell: 331-3888 (STD, 10 V)
Farnell: 331-4145 (LowESR, 35 V)
Taiyo: CE GMK325 F106ZH-T
Farnell: 331-4066 (LowESR, 10 V)
Order code
