Siegenia AEROPAC Original Operating Instructions

Wall mounted ventilator with noise absorbtion.
Hide thumbs Also See for AEROPAC:
Table of Contents

Advertisement

Quick Links

ORIGINAL OPERATING
INSTRUCTIONS
AEROPAC
Wall mounted ventilator with noise absorbtion.
AERO
Window systems
Door systems
Comfort systems

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AEROPAC and is the answer not in the manual?

Questions and answers

Related Manuals for Siegenia AEROPAC

Summary of Contents for Siegenia AEROPAC

  • Page 1 ORIGINAL OPERATING INSTRUCTIONS AERO AEROPAC Wall mounted ventilator with noise absorbtion. Window systems Door systems Comfort systems...

  • Page 2: Table Of Contents

    AEROPAC Original operating instructions Contents 1. Target group of this documentation ....................31 2. Intended use ........................... 31 3. Dimensions ............................. 32 4. Safety notes ............................ 32 5. Scope of delivery / features ......................33 6. Installation ............................34 7. Unit function ............................ 44 8.

  • Page 3: Target Group Of This Documentation

    • The unit is not suitable for use in swimming pools and/or damp locations. • Be sure to mount the supplied SIEGENIA weather grille for the protection of the unit from the outer side. • Do not install the unit in contaminated rooms and ensure that no hazardous substances can be drawn in.

  • Page 4: Dimensions

    Insert the Euro mains plug of the standard connecting cable only into a suitable 230 V AC mains power supply socket. If the mains connection cable for the unit is damaged, it must be replaced by SIEGENIA, its customer service department or an equally qualified person to eliminate hazards.

  • Page 5: Scope Of Delivery / Features

    Original operating instructions AEROPAC 5. Scope of delivery / features Item Designation AEROPAC smart AEROPAC wall-mounted ventilator with G3 dust filter Ventilation pipe Ø 80 mm, length 500 mm Weather grille Bag of screws (2 screws, 2 dowels, 1 plug)

  • Page 6: Installation

    • To prevent damage to the high-quality surface of the unit, it is advisable to wear suitable gloves during the installation. 6.2 Additional requirements for AEROPAC smart • The AEROPAC smart should be installed to be as free from interference as possible. The following interferences can have a negative influence on the WLAN signal: Water lines...
  • Page 7 Original operating instructions AEROPAC 6.3 Recommended unit position 07.2019...
  • Page 8 3. Drill core hole. Using a hammer drill at an angle of approx. 2° to 5°, drill a hole through to the outside wall. Attention! If the AEROPAC is combined with a vent duct, the corresponding assembly instructions must be observed.
  • Page 9 Original operating instructions AEROPAC 6.5 Drilling the mounting holes and inserting the fixing screws 1. Drill the two marked mounting holes and, if required, the additional mounting hole (B) (all drilled holes should have a diameter of 8 mm and be at least 45 mm deep).
  • Page 10 AEROPAC Original operating instructions 6.6.1 Recommendation for installation of the ventilation pipe The connection joint between the ventilation pipe and the core bore hole must be properly sealed inside the room and outside. Please note the following: • Ensure that the gap to be sealed is wide enough to allow for movement in the materials.
  • Page 11 Original operating instructions AEROPAC 6.6.3 Sealing the ventilation pipe on the room side To ensure that no warm and humid indoor air enters the outside wall, the connection joint inside the room must be air-tight. We recommend the use of an acrylic sealing compound (observe the manufacturer’s instructions).
  • Page 12 AEROPAC Original operating instructions 6.7 Mounting the weather grille 1. Sealing the ventilation pipe on the outside. Recommendation: To prevent three-point adhesion from occurring, insert a separating layer such as a round cord into the gap. 2. Sealing the weather grille:...
  • Page 13 Original operating instructions AEROPAC 6.8 Connecting the mains cable 6.8.1 Standard connection • The length of the integrated mains cable is set at the factory to approx. 1.50 m. • The mains cable can be adapted to suit the local conditions (maximum cable length is approx.
  • Page 14 AEROPAC Original operating instructions 6.9 AEROPAC Fixing and connecting 1. Guide the mounting openings on the rear of the unit over the fixing screws and push the unit downwards. 2. Afterwards, check that the unit is secure. 3. Press the two markings on the top of the front panel while pulling the panel towards you.
  • Page 15 AEROPAC 6.10 AEROPAC Additional securing (optional) The AEROPAC can be secured with an additional screw (not included in the scope of delivery), e. g. if the unit is to be turned by 180° and mounted: • Drilling additional mounting holes with a drilling template: Remove the unit from the wall and perform steps 6.4 + 6.5 (see pages 36 + 37).

  • Page 16: Unit Function

    AEROPAC Original operating instructions 7. Unit function The wall-mounted ventilators AEROPAC SN and AEROPAC smart uses an electrically operated blower to quietly draw in fresh air from the outside and provide controlled and energy-efficient filtered air inside. When the blower is switched off, the unit equalises the pressure of the indoor and outdoor air to allow fresh air from the outside to flow inside (pressure differential ventilation).
  • Page 17 /h (max. indicator flashes) 8.3 Operation via smartphone or tablet The AEROPAC smart can be controlled by a tablet or smartphone. Please follow the enclosed quick start instructions (H47.MOTS005EN). Overview of the device functions • Control of the blower performance •...
  • Page 18 AEROPAC Original operating instructions 8.4 Timer function The Timer button is used to activate/deactivate the timer function. When the timer is activated, the timer starts the unit for a preset run time (in hours). This is preset at the factory to 8 hours.

  • Page 19: Care And Maintenance

    • Never clean the unit with a high-pressure cleaner or steam-jet cleaner. • Clean the AEROPAC with a cloth moistened with a mild soap solution or cleaning agent. • Always clean the G3 dust filter manually (e.g. with a vacuum cleaner, wash out using a grease-dis- solving cleaning agent).
  • Page 20 AEROPAC Original operating instructions 9.2 Replacing the filter The filter must be replaced when the air throughput starts to diminish. The L filter change indicator appears on the display after an operation period of six months. Note: Filters for various uses can be found in the chapter Accessories (page 52).
  • Page 21 Original operating instructions AEROPAC 9.3 Cleaning the air canal 9.3.1 Removing the protective grid • If there is a build-up of dirt in the air canal of the unit, it must be cleaned. • To do this, it is necessary to remove the filter as well as the protective grid.
  • Page 22 AEROPAC Original operating instructions 9.3.2 Installation of the protective grid 1. Insert the protective grid into the guide groove on the right and on the left. 2. Press the protective grid lightly against the rear panel. At the same time, carefully lift the fastening clip and push into the locking mechanism.

  • Page 23: Rectification Of Malfunctions

    In case of a malfunction, do not open the device or try to repair it under any circumstances. If the problem is not listed in the table below, please contact your installation firm or SIEGENIA directly: Tel. +49 271 3931-0...

  • Page 24: Accessories

    All sliders closed 57 dB n,e,w Air throughput with blower G3 filter approx. 30 - 180 m (AEROPAC, AEROPAC smart) F5 filter approx. 15 - 160 m Activated carbon filter approx. 15 - 160 m Air throughput without blower G3 filter approx.

  • Page 25: Feedback On Documentation

    12 % / <10 % (at +20 Pa and –20 Pa) Air tightness between inside and outside 4.2 m³/h 13. Feedback on documentation We welcome your comments and suggestions on how to improve our documentation. Please email your comments to dokumentation@siegenia.com. 07.2019...

  • Page 26: Eu Declaration Of Conformity With Regard To Ce Marking

    Original operating instructions 14. EU Declaration of Conformity with regard to CE marking For our product AEROPAC, we confirm that the general safety of the defined product, in accordance with Directive 2001/95/EC, is compliant with the relevant protection requirements which are laid down in the Council Directives about electrical and electronic products.
  • Page 28 Phone: + Industriestraße Telefax: + Wilnsdorf info@sie enia.com GERMANY www.sie enia.com Hun ary Phone: + SIEGENIA worldwide: Austria Phone: + Italy Phone: + Belarus Phone: + Poland Phone: + Benelux Phone: + Russia Phone: + China Phone: + South Korea Phone: +...

This manual is also suitable for:

Aeropac sn
