DEMO MANUAL DC1533A

PARTS LIST

ITEM QTY
Required Circuit Components
1 1
2 1
3 1
4 1
5 1
6 1
Optional Demo Circuit Components
1 0
2 0
3 0
4 0
5 0
6 0
7 0
Hardware
1 6
2 1
3 1
4 4
6
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
REFERENCE PART DESCRIPTION
C1 CAP ., X7R, 4.7μF , 25V, 10%, 1206
C2 CAP ., X5R, 22μF , 16V, 10%, 1206
C3 CAP ., X7R, 10nF , 16V, 10%, 0603
R1 RES., CHIP , 130k, 1% ,0603
R2 RES., CHIP , 60.4k, 1% , 0603
U1 I.C., LTM8045EY#PBF , BGA
CIN1 CAP ., SMT, 47μF , 50V
C4 CAP ., X7R, 47μF , 16V, 20%, 1210
C5 CAP ., X7R, 4.7μF , 25V, 10%, 1206
L1, L2 IND., 1.0μH, 20%,1812
R3 RES., 0603
R4 RES., CHIP , 0Ω, 0603
R5, R6 RES., CHIP , 0603
E1-E6 TESTPOINT, TURRET, .095"
JP1 2MM SINGLE ROW HEADER, 3 PIN
XJP1 SHUNT, .079" CENTER
(STAND-OFF) STAND-OFF , NYLON 0.375" TALL
MANUFACTURER/PART NUMBER
NIC, NMC1206X7R475K25TRPLPF
AVX, 1206YD226KAT2A
AVX, 0603YC103KAT2A
VIAHSY, CRCW0603130KFKEA
VISHAY, CRCW060360K4FKED
LINEAR TECH., LTM8045EY#PBF
SUNCON, 50CE47BS
MURATA, LQH43CN1R0M03
VISHAY, CRCW06030000Z0EA
MILL-MAX, 2501-2-00-80-00-00-07-0
SAMTEC, TMM-103-02-L-S
SAMTEC, 2SN-BK-G
KEYSTONE, 8832(SNAP ON)
dc1533af
