DEMO MANUAL DC1687A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 2 C1, C2
2 1 C4
3 1 C6
4 1 C7
5 1 C8
6 1 C9
7 1 C10
8 1 C11
9 1 C12
10 1 C13
11 1 L1
12 2 R1, R6
13 1 R2
14 1 R3
15 1 R4
16 1 R7
17 1 U1
Additional Demo Board Circuit Components
1 0 C3
2 0 C5
3 0 D1
4 0 D2
5 0 R5
Hardware For Demo Board Only:
1 4 E1–E4
2 2 JP1, JP2
3 2 XJP1, XJP2
4 4
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP , CER, 0.10µF , 16V, X7R, ±20%, 0402
CAP , CER, 33pF , 50V, C0G, 5%, 0402
CAP , CER, 47µF , 10V, 20%, X5R, 1812
CAP , CER, 1.0µF , 25V, X5R, 0603
CAP , CER, 3300pF , 50V, 5%, NP0, 0603
CAP , CER, 4.7µF , 6.3V, X5R, 20%, 0603
CAP , CER, 4.7µF , 50V, 20%, X7R, 1812
CAP , CER, 10pF , 50V, C0G, 0402
CAP , CER, 1.0µF , 50V, X7R, 20%, 1206
CAP , CER, 0.1µF , 50V, 20%, X7R, 0805
INDUCTOR, 10µH, ±20%
RES, 1.00MΩ, 1/16W, 1%, 0402, SMD
RES, 249kΩ, 1/16W, 1%, 0402, SMD
RES, 15.0kΩ, 1/10W, 1%, 0402, SMD
RES, 60.4kΩ, 1/10W, 1%, 0402, SMD
RES, 47.5kΩ, 1/16W, 1%, 0402, SMD
40V, 2A Buck Boost DC/DC Converter
CAP , CER, 1000PF , 50V, 20%, X7R, 0402 (OPT)
CAP , ALUM, 150µF , 50V, 20%, RADIAL (OPT)
DIODE SCHOTTKY, 20V, 1A, SOD323 (OPT)
DIODE SCHOTTKY, 60V, 3A, SMA (OPT)
RES, 0402 (OPT)
TP , TURRET, 0.094", PBF
JMP , 3-PIN 1 ROW .079CC
SHUNT, .079" CENTER
SPACER STACKING #4 SCREW NYLON .500"
MANUFACTURER/PART NUMBER
TDK, C1005X7R1C104M
TDK, C1005C0G1H330J
TDK, C4532X5R1A476M
TDK, C1608X5R1E105M
TDK, C1608C0G1H332J
TDK, C1608X5R0J475M
TDK, C4532X7R1H475M/2.00
TDK, C1005C0G1H100D
TDK, C3216X7R1H105M
TDK, C2012X7R1H104M/0.85
COILCRAFT, MSS1048-103MLB
VISHAY, CRCW04021M00FKED
VISHAY, CRCW0402249KFKED
PANASONIC, ERJ-2RKF1502X
PANASONIC, ERJ-2RKF6042X
VISHAY, CRCW040247K5FKED
LINEAR TECHNOLOGY, LTC3115EDHD-1
TDK, C1005X7R1H102M
PANASONIC, EEU-FM1H151
NXP SEMI, PMEG2010EA
DIODES INC.,B360A-13
MILL-MAX, 2501-2-00-80-00-00-07-0
SAMTEC, TMM-103-02-L-S
SAMTEC, 2SN-BK-G
KEYSTONE, 8833
