4. Solder the exposed copper together with braid to connect the terminal labeled V
in Figure 6. The terminal labeled V
5. Change C2 to 100μF 6.3V 1206 or 1210. Change R1 to 115k to optimize the switching frequency.
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
DEMO MANUAL DC1533A
–
is now GND.
OUT
Figure 6
–
to the ground plane, as shown
OUT
